Установкa Thermo King схема ELECTRICAL COMPONENTS (M35B) – 182C4
Обновление от: 6/23/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | ASQ | PANEL - control (M32, M33, M35, M36, see 144D11; M40, M43-M51, M55, see 143G12) | 1 | |
| 2 | 104-652 | MOTOR - condenser fan (G.E, see note) | 2 | |
| 3 | 104-651 | MOTOR - evaporator blower (G.E, see note) | 1 | |
| 4 | 55-9550 | STUD - terminal (red) | 1 | |
| 5 | 55-9551 | STUD - terminal (black) | 1 | |
| 55-3066 | LOCKWASHER (internal thread) | 4 | ||
| 55-448 | FLATWASHER | 4 | ||
| 55-671 | NUT | 4 | ||
| 6 | 55-9700 | SCREW - stud | 4 | |
| 55-2001 | FLATWASHER | 4 | ||
| 55-4560 | NUT | 4 | ||
| 7 | 99-4661 | NAMEPLATE - Negative | 1 | |
| 8 | 99-4660 | NAMEPLATE - Positive | 1 | |
| 9 | 40-975 | KIT - temperature sensor (ambient air) | 2 | |
|
40-975 OEM | Датчик температуры к-т, некалиброванный | 10 310 ₽ |
|
|
10-40-975 | Датчик температуры к-т, некалиброванный | 4 660 ₽ |
|
| NSS | SENSOR - ungraded (18 in) | 1 | ||
| 41-5210 | COLLAR - crimp | 2 | ||
| 92-846 | HEATSHRINK (1/2 in) | 2 | ||
| 10 | 41-1246 | HARNESS - thermostat (ambient air) | 1 | |
| 11 | 91-5575 | BRACKET - thermostat | 1 | |
| 55-2991 | SCREW - thermostat | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-6721 | INSERT | 2 | ||
| 12 | 55-5900 | CONNECTOR - liquid tite | 6 | |
| 13 | 55-5257 | CONNECTOR - liquid tite | 1 | |
| 14 | 33-1692 | GROMMET (3/8 id, 3/16 groove) | 2 | |
| 33-547 | GROMMET (3/8 id, 1/8) | 1 | ||
| 33-316 | GROMMET (1 id, 3/16) | 1 | ||
| 33-1815 | GROMMET (9/16 id, 3/16 groove) | 1 | ||
| 15 | 41-659 | HARNESS - evaporator | 1 | |
| 16 | 55-547 | CLAMP (0.375 dia) | 1 | |
| 55-9309 | CLAMP (0.500 dia) | 1 | ||
| 55-9423 | CLAMP (0.500 dia) | 2 | ||
| 55-9702 | CLAMP (0.625 dia) | 3 | ||
| 55-9311 | CLAMP (1.00 dia) | 1 | ||
| 55-2911 | SCREW - clamp | A/R | ||
| 55-2001 | FLATWASHER | A/R | ||
| 55-4560 | NUT | A/R | ||
| 17 | 44-6965 | SWITCH - condenser fan (for connectors see 115D14) | 1 | |
| 41-307 | SWITCH - only | 1 | ||
| 18 | 41-5305 | HARNESS - control (for connectors see 115D14) | 1 |
