Установкa Thermo King схема ELECTRICAL COMPONENTS – 180E2
Обновление от: 9/13/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 40-791 | KIT - sensor (universal) | A/R | |
| 40-791 OEM | Датчик оттайки | 8 070 ₽ |
|
|
| 2 | 41-3685 | HARNESS - evaporator (two fan, see 180D9) | 1 | |
| 41-4002 | HARNESS - evaporator (three fan, see 183B6) | 1 | ||
| 3 | 92-2777 | BRACKET - power cable (11/4 cable) | 1 | |
| 92-5660 | BRACKET - power cable (10/4 cable) | 1 | ||
| 51-1445 | SCREW - bracket | 2 | ||
| 51-1446 | LOCKWASHER | 2 | ||
| 51-1441 | FLATWASHER | 2 | ||
| 55-9054 | WASHER - insulator | 2 | ||
| 4 | 45-1992 | CABLE - power (19.2 meters, 63 ft, 11/4 ga) | 1 | |
| 45-237 | CABLE - power (24 meters, 78 ft, 10/4 ga) | 1 | ||
| 5 | 41-1976 | PLUG - power (Minnekes) | 1 | |
| 44-4051 | PLUG - power (10/4) | 1 | ||
| 44-9891 | TERMINAL - pin | 7 | ||
| 6 | 41-4473 | SWITCH - lpco | 1 | |
| 7 | 91-8140 | SPRING - heater | 6 | |
| 8 | 41-2838 | HARNESS - sensor (humidity, MPC) | 1 | |
| 9 | 104-759 | MOTOR - condenser fan (see 180D8) | 1 | |
| 77-1498 | BEARING - shaft end | 1 | ||
| 77-1401 | BEARING - opposite end | 1 | ||
| 10 | 41-2953 | HARNESS - condenser fan (see 180D8) | 1 | |
| 11 | 104-691 | MOTOR - evaporator fan (two fan see 180D9, three fan see 183B6) | A/R | |
| 77-1498 | BEARING - shaft end | 1 | ||
| 77-1401 | BEARING - opposite end | 1 | ||
| 12 | 41-3593 | HARNESS - control box | 1 | |
| 13 | 45-1927 | HEATER (680W, 2 meter leads, see 259A4) | 6 | |
| 14 | 91-8142 | BRACKET - heater (15.4/404 long, MAGNUM) | 1 | |
| 91-8634 | BRACKET - heater (13.6/347 long, MAGNUM SL-40) | 1 | ||
| 92-234 | BRACKET - heater (12.3/313 long, MAGNUM SL-40) | 1 | ||
| 15 | 91-8467 | BRACKET - heater (13.8/350 long, MAGNUM) | 2 | |
| 91-8629 | BRACKET - heater (12.0 long, MAGNUM SL-40) | 2 | ||
| 92-235 | BRACKET - heater (11.4/290 long, MAGNUM SL-20) | 2 | ||
| 51-1447 | SCREW - bracket | 11 | ||
| 16 | 41-5103 | VALVE - solenoid | 1 | |
| 41-3301 | COIL - valve | 1 | ||
| 17 | 41-3401 | THERMOSTAT - defrost termination | 1 | |
| 51-336 | SCREW - thermostat | 2 | ||
| 18 | 102-795 | COMPRESSOR - scroll (see 180E1) | 1 | |
| 19 | NSS | BOX - control (see 158A3) | 1 | |
| 20 | 40-786 | CABLE - compressor | 1 | |
| 21 | 41-4004 | SWITCH - hpco | 1 | |
| 22 | 61-2057 | VALVE - digital | 1 | |
| 41-7937 | COIL (only) | 1 | ||
| 23 | 41-9220 | SENSOR - humidity | 1 | |
| 24 | NSS | PANEL - USDA receptacle (see 173B1) | 1 | |
| NSS | PANEL - USDA receptacle (see 183B3, SL-40 & 20) | 1 | ||
| 25 | 40-776 | KIT - thermistor | 1 | |
| 26 | 51-270 | CONNECTOR - liquid tite | 1 | |
| 27 | 41-6150 | TRANSDUCER - suction (200 psi) | 1 | |
| 28 | 41-6151 | TRANSDUCER - discharge (200 psi) | 1 |
