Установкa Thermo King схема LRC 35 SIRIO GEN REFERENCE SHEET – 17U88
Обновление от: 12/13/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 901879 | LRC35 SIRIO GENOVA | 11/12 | ||
| 096773 | Kit - Condenser LRC MKII - 3 Condensers | 11/12 | ||
| 096775 | Kit - Circuit LRC35 HA | 11/12 | ||
| 096687 | Kit - Blower LRC MKII | 11/12 | ||
| 096689 | Kit - Covers LRC MKII | 11/12 | ||
| 096693 | Kit - Fresh Air LRC MKII | 11/12 | ||
| 096694 | Kit - Water Eliminator LRC MKII | 11/12 | ||
| 096607 | Kit - Fluids LRC35 HA | 11/12 | ||
| 096705 | Kit - Insulation TX | 11/12 | ||
| 096696 | Kit - Heater LRC MKII - 24kW | 11/12 | ||
| 096710 | Kit - Evaporator 35kW LRC MKII 5 Rows | 11/12 | ||
| 096711 | Kit - Compressor LRC 35kW | 11/12 | ||
| 096771 | Kit - Color LRV RAL 9005 (Black) | 11/12 | ||
| 096772 | Kit - Frame LRC Return Air Damper | 11/12 | ||
| 096686 | Kit - Condenser Fans LRC MKII | 11/12 | ||
| 096800 | Kit - Electro LRC35 MKII SIRIO | 11/12 | ||
| 096774 | Kit - Return Air Damper LRC | 11/12 |
