Установкa Thermo King схема CONTACTOR & CIRCUIT BREAKER GROUP – 176A8
Обновление от: 4/8/02
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-161 | SHEET - mounting | 1 | |
| 55-9553 | NUT - captive | 8 | ||
| 2 | 91-9375 | CHANNEL - din rail | 1 | |
| 55-5130 | RIVET - channel | 11 | ||
| 3 | 41-4777 | TERMINAL - input | 1 | |
| 4 | 41-3514 | BUSBAR | 1 | |
| 5 | 41-4684 | BUSBAR | 2 | |
| 6 | 41-3889 | BUSBAR | 1 | |
| 7 | 41-3512 | BREAKER - circuit (QCOM1 & QCOM2) | 2 | |
| 8 | 41-3510 | BREAKER - circuit (QCFM1 & QCFM2, 3.2 amp) | 2 | |
| 9 | 41-2936 | BREAKER - circuit (QEFM, 11 amp) | 1 | |
| 10 | 41-2931 | BLOCK - contact (aux switch) | 6 | |
| 11 | 41-3811 | RELAY - shunt release (QHSR1 & QHSR2) | 2 | |
| 12 | 41-4778 | ELEMENT - coupling | 2 | |
| 13 | 41-2944 | ELEMENT - coupling | 2 | |
| 14 | 41-3516 | CONTACTOR (KCOM1 & KCOM2) | 2 | |
| 15 | 41-3888 | CONTACTOR (KHTR1 & KHTR2) | 2 | |
| 16 | 41-3513 | BREAKER - circuit (QHTR1 & QHTR2) | 2 | |
| 16 | 92-2002 | BRACKET - contactor | 2 | |
| 55-7663 | SCREW - bracket | 4 | ||
| 55-7861 | LOCKWASHER | 4 | ||
| 55-7697 | FLATWASHER | 4 | ||
| 55-9564 | INSERT - threaded | 4 | ||
| 18 | 91-6465 | CLAMP - rail | 6 | |
| 19 | 41-4279 | COVER - scale | 5 | |
| 20 | 92-2100 | BRACKET - contactor | 1 | |
| 21 | 41-3511 | BREAKER - circuit (QSUP, 10 amp) | 1 | |
| 22 | 41-2943 | ELEMENT - coupling | 3 | |
| 24 | 41-3891 | TERMINAL - input | 1 | |
| 25 | 309-3433 | CHANNEL - din rail | 2 | |
| 26 | 41-3887 | CONTACTOR (KICFM1, KICFM2) | 2 | |
| 27 | 41-4727 | CONTACTOR (KIEFM) | 1 | |
| 28 | 41-2945 | SUPPRESSOR - module (S0) | 2 | |
| 29 | 41-2942 | SUPPRESSOR - module (size SO) | 3 |
