Установкa Thermo King схема CONDENSER ELECTRICAL (ClimaAIRE) – 175E1
Обновление от: 4/9/04
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-7991 | SWITCH - pressure | 1 | |
| 2 | 44-3292 | THERMOSTAT - defrost termination | 1 | |
| 55-7664 | SCREW - switch | 2 | ||
| 55-2202 | LOCKWASHER | 2 | ||
| 55-2201 | FLATWASHER | 2 | ||
| 55-8120 | FLATWASHER | 2 | ||
| 55-7866 | NUT - captive | 2 | ||
| 3 | 78-1294 | FAN - condenser (see 175D3) | 2 | |
| 78-1294 OEM | Вентилятор конденсатора | 19 470 ₽ |
|
|
|
10-33-2999 | Прокладка ГБЦ, Yanmar 482, SB-XXX/SB-III/SL/SLe | 13 280 ₽ |
|
| PP-33-2999 | Прокладка ГБЦ, Yanmar 482, SB-XXX/SB-III/SL/SLe | 4 600 ₽ |
|
|
| 4 | 41-4121 | HARNESS - condenser (for connectors see 115D14) | 1 | |
| 5 | 41-2767 | CONNECTOR (6-pin, female) | 1 | |
| 6 | 41-3855 | TERMINAL - connector (10-pin, female) | 1 | |
| 7 | 44-2788 | TERMINAL - fork | 1 |
