Установкa Thermo King схема EVAPORATOR BLOWERS – 174C9
Обновление от: 10/3/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 307-612 | HOUSING - blower (ccw) | 1 | |
| 2 | 78-1333 | BLOWER (ccw) | 1 | |
| 3 | 307-614 | HOUSING - blower (cw) | 1 | |
| 4 | 78-1333 | BLOWER (cw) | 1 | |
| 55-7752 | SCREW - orifice | 8 | ||
| 55-6996 | LOCKWASHER | 8 | ||
| 55-7075 | FLATWASHER | 8 | ||
| 5 | 304-2879 | MOTOR - blower | 1 | |
| 55-7825 | NUT - motor | 4 | ||
| 55-7066 | LOCKWASHER | 4 | ||
| 55-6988 | FLATWASHER | 4 | ||
| 6 | 305-1413 | CONNECTOR - harness | 2 | |
| 305-1408 | NUT - sealing | 2 | ||
| 7 | 40-974 | KIT - sensor (graded) | 1 | |
|
40-974 OEM | Датчик температуры калиброванный | 8 770 ₽ |
|
|
10-40-974 | Датчик температуры калиброванный | 3 500 ₽ |
|
| 8 | 55-9555 | NUT - sensor | 1 | |
| 9 | 55-6010 | PLUG - button | 2 | |
| 10 | 99-4931 | NAMEPLATE - arrow | 2 | |
| 11 | 99-8506 | NAMEPLATE - Caution, Fan | 2 | |
| 12 | 307-604 | RING - inlet | 4 | |
| 13 | 98-6329 | SUPPORT - blower | 1 | |
| 55-7825 | NUT - base | 8 | ||
| 55-7066 | LOCKWASHER | 8 | ||
| 55-6988 | FLATWASHER | 8 | ||
| 14 | 33-3581 | INSULATION - blower | 1 | |
| 15 | 33-3582 | INSULATION - center | 1 | |
| 16 | 33-3583 | INSULATION - blower | 1 |
