Установкa Thermo King схема ELECTRICAL COMPONENTS – 173E1
Обновление от: 6/23/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | ASQ | PANEL - control | 1 | |
| 2 | 104-740 | MOTOR - condenser fan | 2 | |
| 99-9084 | NAMEPLATE - Arrow | 2 | ||
| 99-6141 | NAMEPLATE - Caution, Fan | 2 | ||
| 3 | 104-741 | MOTOR - evaporator blower (see 153G9) | 1 | |
| 99-9084 | NAMEPLATE - Arrow | 1 | ||
| 99-6141 | NAMEPLATE - Caution, Fan | 1 | ||
| 4 | 55-3167 | STUD - terminal (ground) | 1 | |
| 55-448 | FLATWASHER | 4 | ||
| 55-3066 | LOCKWASHER | 4 | ||
| 55-3672 | LOCKWASHER (internal tooth) | 1 | ||
| 55-671 | NUT (hexjam, brass) | 4 | ||
| 5 | 41-4842 | HARNESS - control (for connectors see 115D14) | 1 | |
| 55-1801 | NUT - connector | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 6 | 55-5900 | CONNECTOR - cable | 6 | |
| 7 | 99-4660 | NAMEPLATE - Positive | 1 | |
| 8 | 99-4661 | NAMEPLATE - Negative | 1 | |
| 9 | 91-1077 | PLATE - connector | 1 | |
| 33-2343 | GASKET - plate | 1 | ||
| 10 | 33-489 | GROMMET (1-1/4 id) | 1 | |
| 33-2001 | GROMMET (7/8 id) | 1 | ||
| 33-367 | GROMMET (5/8 id) | 2 | ||
| 33-1611 | GROMMET (1/8 id) | 2 | ||
| 33-1809 | GROMMET (1/2 id) | 1 | ||
| 11 | 40-975 | KIT - temperature sensor | 2 | |
|
40-975 OEM | Датчик температуры к-т, некалиброванный | 10 310 ₽ |
|
|
10-40-975 | Датчик температуры к-т, некалиброванный | 4 660 ₽ |
|
| NSS | SENSOR - ungraded (18 in) | 1 | ||
| 41-5210 | COLLAR - crimp | 2 | ||
| 92-846 | HEATSHRINK (1/2 in) | 2 | ||
| 55-547 | CLAMP - sensor | 2 | ||
| 55-3027 | SCREW - clamp | 2 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-4560 | NUT | 2 | ||
| 12 | 41-3672 | HARNESS - compressor (for connectors see 115D14) | 1 | |
| 13 | 44-6965 | SWITCH - pressure (2 speed condenser fan, R134a) | 1 | |
| 41-307 | SWITCH - only (200 psi, for connectors see 115D14) | 1 | ||
| 14 | 41-3590 | CONTROLLER - motor | 1 | |
| 15 | 91-8729 | BRACKET - terminal board | 1 | |
| 16 | 44-5555 | BOARD - terminal | 1 | |
| 55-3843 | SCREW - board | 4 | ||
| 55-2001 | FLATWASHER | 8 | ||
| 55-2964 | LOCKWASHER | 4 | ||
| 91-8528 | MARKSTRIP | 1 |
