Установкa Thermo King схема CONDENSER REFRIGERATION – 170D4
Обновление от: 10/13/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-1028 | COMPRESSOR - 15XD (12V, see 169C2) | 1 | |
| 2 | 66-7525 | HOSE - discharge | 1 | |
| 3 | 33-2350 | O-RING - compressor | 1 | |
| 4 | 33-566 | O-RING - hose to adapter | 1 | |
| 5 | 55-6838 | NUT - shoulder | 1 | |
| 6 | 55-6779 | ADAPTER - bulkhead | 1 | |
| 7 | 66-9040 | TUBE - adapter to separator | 1 | |
| 8 | 55-6837 | SHOULDER - o-ring | 1 | |
| 9 | 91-6020 | BRACKET - tube | 1 | |
| 10 | 66-8548 | SEPARATOR - oil (see 152D11) | 1 | |
|
66-8548 OEM | Масляный сепаратор, V/VM-Series | 18 750 ₽ |
|
|
10-66-8548 | Масляный сепаратор, V/VM-Series | 4 870 ₽ |
|
| 11 | 33-566 | O-RING (1/2) | 2 | |
| 12 | 67-1574 | COIL - condenser | 1 | |
| 92-1675 | PLATE - reinforcement | 1 | ||
| 55-2114 | NUT - coil | 1 | ||
| 55-3504 | LOCKWASHER | 1 | ||
| 55-2958 | FLATWASHER | 1 | ||
| 99-7245 | STRIP - neoprene | 1 | ||
| 13 | 55-1464 | ELBOW | 1 | |
| 14 | 67-1210 | TANK - receiver | 1 | |
| 15 | 33-2419 | O-RING - liquid indicator | 1 | |
| 16 | 66-9918 | INDICATOR - liquid | 1 | |
| 17 | 55-7799 | CLAMP - receiver tank | 1 | |
| 18 | 61-600 | DEHYDRATOR | 1 | |
|
US-61-600 | Дегидратор, SL/SLe/SLX/SLXe/SMX/SMX-II/SB / UT-800/1200 | 6 880 ₽ |
|
| 10-61-600 | Дегидратор, SL/SLe/SLX/SLXe/SMX/SMX-II/SB / UT-800/1200 | 3 420 ₽ |
|
|
|
PP-61-600 | Дегидратор, SL/SLe/SLX/SLXe/SMX/SMX-II/SB / UT-800/1200 | 2 090 ₽ |
|
| 19 | 33-2115 | O-RING - inlet | 1 | |
| 20 | 33-566 | O-RING - outlet | 1 | |
| 21 | 55-7800 | CLAMP | 3 | |
| 22 | 91-8781 | BRACKET - dehydrator | 1 | |
| 55-3136 | RIVET - bracket | 4 | ||
| 23 | 66-9041 | TUBE - coil to valve | 1 | |
| 24 | 55-6389 | CLAMP - tube | 1 | |
| 55-2979 | SCREW - clamp | 1 | ||
| 55-1800 | LOCKWASHER | 1 | ||
| 55-2086 | FLATWASHER | 1 | ||
| 25 | 66-3693 | VALVE - defrost (see 64C6) | 1 | |
| 26 | 66-7014 | TUBE - valve to adapter | 1 | |
| 27 | 91-6021 | BRACKET - support tube | 1 | |
| 28 | 55-6809 | ADAPTER - bulkhead | 1 | |
| 29 | 55-6780 | NUT - bulkhead | 1 | |
| 30 | 66-9890 | GAUGE - suction | 1 | |
| 31 | 61-1240 | GAUGE - discharge | 1 | |
| 55-5130 | RIVET - gauge | 6 | ||
| 32 | 92-1669 | BRACKET - gauge | 1 | |
| 33 | 91-8837 | STRIP - sealing | A/R | |
| 34 | 66-1239 | TUBE - suction | 1 | |
| 35 | 66-1241 | TUBE - discharge | 1 | |
| 36 | 55-459 | COUPLING | 4 |
