Установкa Thermo King схема CONTROL PANEL (ClimaAIRE - 1000/1004) – 170C4
Обновление от: 9/01/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-1292 | FUSE (5 amp) | 1 | |
|
10-41-1292 | Предохранитель 5 ампер 10 шт | 1 860 ₽ |
|
| 2 | 44-9344 | FUSE (15 amp) | 5 | |
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 3 | 41-1932 | FUSE (1 amp) | 1 | |
| 4 | 55-7367 | NUT | 1 | |
| 5 | 55-7034 | NUT | 6 | |
| 6 | 99-3427 | MOUNT - cable tie | 2 | |
| 55-3010 | RIVET - mount | 2 | ||
| 7 | 41-5657 | RELAY (13 for CA I, 12 for CA I D & CA II) | A/R | |
| 8 | 41-243 | STRAP - door | 1 | |
| 9 | 41-4157 | SENSOR - temperature | 1 | |
| 10 | 92-916 | PANEL - control | 1 | |
| 55-7373 | NUT - captive | 2 | ||
| 11 | 92-2767 | NAMEPLATE - fuse | 1 | |
| 12 | 41-4154 | BOARD | 1 | |
| 13 | 55-7033 | FLATWASHER | 1 | |
| 14 | 55-7075 | FLATWASHER | 4 | |
| 15 | 55-7170 | LOCKWASHER | 4 | |
| 16 | 55-7169 | SCREW - strap | 1 | |
| 17 | 55-7172 | SCREW - panel | 4 | |
| 18 | 55-9623 | STUD - board, self clinching | 7 | |
| 19 | 55-9624 | SPACER | 6 | |
| 20 | 41-2978 | FUSE (20 amp) | 3 | |
| 30-41-2978 | Предохранитель 32V 20А | 500 ₽ |
|
|
| 21 | 33-489 | GROMMET (1.25 id) | 1 | |
| 22 | 51-310 | NUT - acorn (plastic) | 1 | |
| 23 | 55-8718 | SPACER | 2 | |
| 24 | 55-2996 | LOCKWASHER | 1 |
