Установкa Thermo King схема FRAME AND INSULATIONS COMPONENTS – 168D8
Обновление от: 9/4/02
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 33-507 | GROMMET (1.125 id) | 3 | |
| 2 | 33-314 | GROMMET (0.312 id) | 1 | |
| 3 | 83-258 | GROMMET (0.250 id) | 2 | |
| 4 | 55-3458 | PIN - cotter | 2 | |
| 5 | 92-672 | INSULATION - evaporator (rear) | 1 | |
| 6 | 92-1255 | INSULATION - evaporator | 1 | |
| 7 | 92-1265 | LID | 1 | |
| 8 | 92-1266 | LID | 1 | |
| 9 | 91-7386 | CLAMP - tube | 2 | |
| 10 | 98-6308 | BASE - curbside | 1 | |
| 11 | 98-6309 | BASE - roadside | 1 | |
| 12 | 92-666 | INSULATION - evaporator (rear) | 1 | |
| 13 | 92-680 | ROD - cover | 2 | |
| 14 | 92-683 | COVER - servomotor | 1 | |
| 15 | 92-721 | COVER - servomotor | 1 | |
| 16 | 92-700 | ANGLE - coil support (roadside) | 1 | |
| 17 | 92-684 | ANGLE - coil support (curbside) | 1 | |
| 18 | 92-1256 | INSULATION - evaporator (curbside) | 1 | |
| 19 | 92-1257 | INSULATION - evaporator (roadside) | 1 | |
| 20 | 92-1258 | INSULATION - evaporator (rear) | 1 | |
| 21 | 92-1259 | INSULATION - evaporator (front) | 1 | |
| 22 | 92-1261 | INSULATION - evaporator (rear) | 1 | |
| 23 | 92-1963 | INSULATION - evaporator (front) | 1 | |
| 24 | 98-6310 | SUPPORT - central | 2 | |
| 25 | 98-6311 | SUPPORT | 2 | |
| 26 | 92-1267 | STIFFENER - rear | 1 | |
| 27 | 92-1268 | STIFFENER - front | 1 | |
| 28 | 92-1262 | INSULATION | 1 | |
| 29 | 92-1964 | INSULATION | 1 | |
| 30 | 92-1264 | STRIP - insulation | 2 | |
| 31 | 92-1965 | INSULATION - evaporator (curbside) | 1 | |
| 32 | 92-1966 | INSULATION - evaporator (roadside) | 1 | |
| 33 | 55-6995 | FLATWASHER | 2 |
