Установкa Thermo King схема REFRIGERATION UNIT - REAR VIEW – 166A1
Обновление от: 11/1/01
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 2 | 509-739 | PLATE - top motor bracket (welded) (360-45332-00) | 1 | |
| 4 | 33-2943 | GASKET - unit container (K28-51596-00) | 1 | |
| 24 | 509-451 | PLATE - LH side (060-54348-00) | 1 | |
| 25 | 509-450 | Z-PROFILE - bottom rear panel (060-54347-00) | 5 | |
| 26 | 509-453 | PANEL - bottom rear (060-54371-00) | 1 | |
| 27 | 509-444 | PANEL - top rear (060-54293-00) | 1 | |
| 28 | 509-449 | Z-PROFILE - top rear panel (060-54344-00) | 5 | |
| 29 | 509-452 | PANEL - LH side (060-54349-00) | 1 |
