Установкa Thermo King схема REFRIGERATION UNIT - ELECTRICAL BOX – 163H3
Обновление от: 9/10/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 11 | 509-679 | BRACKET (w/ receptacle) (360-50950-00) | 2 | |
| 12 | 509-687 | HOUSING - electrical box (360-53077-00) | 1 | |
| 13 | 504-381 | BOOT - circuit breaker (K24-18164-00) | 1 | |
| 14 | 504-422 | BREAKER - circuit (8A) (K24-20565-00) | 1 | |
| 15 | 509-1139 | LABEL - on/off/cb/cond fan (K35-51905-00) | 1 | |
| 509-1104 | LABEL - on/off/cb (K35-50090-00) | 1 | ||
| 16 | 92-239 | BOOT - switch (K24-17239-00) | 1 | |
| 18 | 509-310 | BRACKET - display panel (060-53085-01) | 1 | |
| 19 | COVER | COVER - display (tilted) (360-54188-01) | 1 | |
| 21 | 504-840 | MULTIPLUG - 3 pole (K25-51537-03) | 1 | |
| 22 | 41-3598 | MULTIPLUG - 8 pole (K25-51537-08) | 2 | |
| 26 | 55-8920 | RECEPTALCE (K21-16180-00) | 2 | |
| 30 | 509-315 | BRACKET - display panel (060-53086-01) | 1 | |
| 31 | 509-1107 | LABEL - power/condition OK (K35-50093-00) | 1 | |
| 36 | 505-151 | RECEPTACLE - 1/4 turn (K21-14762-00) | 4 | |
| 37 | 55-2657 | RETAINER - 1/4 turn (K21-14472-00) | 4 | |
| 38 | 505-226 | STUD - 1/4 turn (K21-51913-04) | 4 | |
| 44 | 504-854 | TRANSFORMER (K25-51544-00) | 1 | |
| 45 | 509-362 | PANEL (060-53335-01) | 1 | |
| 46 | 504-1140 | PHASE SENSOR (K31-51550-00) | 1 | |
| 48 | 504-1164 | MANUAL CONTROL PRINT (K31-51760-00) | 1 | |
| 49 | 504-843 | MULTIPLUG - 6 pole (K25-51537-06) | 1 | |
| 50 | 504-846 | MULTIPLUG - 10 pole (K25-51537-10) | 1 | |
| 51 | 41-4527 | MULTIPLUG - 7 pole (K25-51537-07) | 1 | |
| 52 | 504-847 | MULTIPLUG - 11 pole (K25-51537-11) | 1 | |
| 53 | 509-966 | COVER - circuit breaker (K28-51607-00) | 2 | |
| 54 | 504-389 | BREAKER - circuit (K24-18744-00) | 1 | |
| 55 | 504-1030 | PROTECTION - contactor (K28-51710-00) | 2 | |
| 56 | 845-1886 | THERMOSTAT (K31-51692-00) | 1 | |
| 57 | 504-1177 | DISPLAY (tilted) (K31-51959-00) | 1 | |
| 58 | 504-865 | TERMINAL - ground (K25-51656-00) | 2 | |
| 59 | 504-864 | TERMINAL (K25-51655-00) | 3 | |
| 60 | 509-1143 | LABEL - terminal (K35-51949-00) | 1 | |
| 62 | 41-2521 | CONTACTOR - compressor (K24-51820-16) | 1 | |
| 63 | 504-493 | CONTACTOR (K24-51820-09) | 6 | |
| 67 | 509-139 | CLAMP - circuit breaker (060-05498-01) | 1 | |
| 68 | 509-373 | TRACK - terminal (060-53486-08) | 1 | |
| 69 | 509-376 | TRACK - contactor/phase sensor (060-53486-38) | 1 | |
| 72 | 504-259 | CABLE - display panel (w/ plug, 3 pole) (360-53165-01) | 1 | |
| 73 | 506-111 | CABLE - display panel/thermostat (w/ plug, 8 pole) (360-50921-05) | 1 | |
| 74 | 504-262 | CABLE - thermostat (w/ plug, 10 pole) (360-53165-04) | 1 | |
| 75 | 504-260 | CABLE - thermostat (w/ plug, 7 pole) (360-53165-02) | 1 | |
| 76 | 504-261 | CABLE - thermostat (w/ plug, 11 pole) (360-53165-03) | 1 | |
| 77 | 504-900 | CONTACT - auxiliary (special type) (K25-51840-07) | 7 | |
| 82 | 504-896 | LIGHT - green (28V) (K25-51802-00) | 1 | |
| 83 | 504-897 | LIGHT - yellow (28V) (K25-51803-00) | 1 | |
| 84 | 509-438 | BRACKET - hourmeter (060-54186-01) | 1 | |
| 85 | 504-714 | HOURMETER (K25-22099-00) | 1 | |
| 86 | 504-266 | CABLE - hourmeter (360-53165-09) | 1 | |
| 97 | 505-408 | PLUG - seal (K28-51785-18) | 2 | |
| 100 | 509-748 | HINGE - electrical box (complete) (360-54986-00) | 1 |
