Установкa Thermo King схема MOTORS, BLOWERS & FANS (G.E. & OHIO MOTORS) – 163G2
Обновление от: 5/22/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 77-2664 | BEARING - flange | 2 | |
| 92-761 | SPACER - bearing | 4 | ||
| 55-2341 | SCREW - flange | 4 | ||
| 55-4931 | FLATWASHER | 4 | ||
| 55-2641 | FLATWASHER | 4 | ||
| 55-4955 | NUT | 4 | ||
| 2 | 77-1834 | RING - inlet | 2 | |
| 3 | 99-8335 | NUTSTRIP | 4 | |
| 55-3035 | RIVET - blind | 4 | ||
| 4 | 78-542 | FAN - condenser (G.E. motor) | 2 | |
| 78-1116 | HUB - condenser fan | 2 | ||
| 55-3089 | SCREW - fan | 2 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 78-1115 | FAN - condenser (M33, M33A, M36A, M55, Ohio motor) | 2 | ||
| 77-1457 | HUB - condenser fan | 2 | ||
| 55-5089 | SCREW - hub | 2 | ||
| 55-2959 | LOCKWASHER | 2 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 5 | 104-476 | MOTOR - condenser fan (27VDC, Ohio, see 85G2) | 2 | |
| 104-652 | MOTOR - condenser fan (27VDC, G.E., see note) | 2 | ||
| 55-2969 | SCREW - motor | 8 | ||
| 55-4727 | FLATWASHER | 8 | ||
| 55-2959 | LOCKWASHER | 8 | ||
| 99-7780 | SPACER - motor mount | |||
| 7 | 98-4625 | TRAY - evaporator motor (G.E. motor) | 1 | |
| 98-5337 | TRAY - evaporator motor (G.E. motor, M44, M45, M50, M55) | 1 | ||
| 98-4625 | TRAY - evaporator motor (Ohio) | 1 | ||
| 55-2969 | SCREW - tray | 12 | ||
| 55-2958 | FLATWASHER | 12 | ||
| 55-2959 | LOCKWASHER | 12 | ||
| 305-1362 | INSERT - threaded | 12 | ||
| 8 | 104-323 | MOTOR - evaporator blower (Ohio, see 76C1) | 1 | |
| 104-651 | MOTOR - evaporator blower (G.E., see note) | 1 | ||
| 55-3490 | SCREW - motor | 4 | ||
| 55-4727 | FLATWASHER | 4 | ||
| 55-2959 | LOCKWASHER | 4 | ||
| 55-6713 | INSERT | 4 | ||
| 9 | 77-2589 | COUPLING - flexible | 2 | |
| 10 | 77-2665 | SHAFT - motor | 2 | |
| 11 | 77-2519 | WHEEL - blower (ccw) | 1 | |
| 12 | 77-2518 | WHEEL - blower (cw) | 1 | |
| 13 | 98-7383 | HOUSING - blower (curbside, incl 15) | 1 | |
| 98-7381 | HOUSING - blower (curbside, incl 15, M40, M44, M45, M46, M47, M50, M55) | 1 | ||
| 14 | 98-7382 | HOUSING - blower (roadside, incl 15) | 1 | |
| 98-7380 | HOUSING - blower (roadside, incl 15, M40, M44, M45, M46, M47, M55) | 1 | ||
| 55-2979 | SCREW - housing | 8 | ||
| 55-4953 | NUT | 2 | ||
| 55-3031 | SCREW - housing | 10 | ||
| 55-2001 | FLATWASHER | 10 | ||
| 55-4560 | NUT | 10 | ||
| 55-2965 | NUT | 10 | ||
| 15 | 99-9316 | PLATE - blower housing cover | 2 |
