Установкa Thermo King схема HARNESS ASSEMBLIES - TEMPERATURE SENSORS – 161C7
Обновление от: 10/3/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-3792 | HARNESS - power supply (assembly) | 1 | |
| 2 | 41-3793 | HARNESS - power cable (assembly) | 1 | |
| 3 | 41-3794 | HARNESS - low voltage supply (assembly) | 1 | |
| 4 | 41-3820 | HARNESS - heater power supply (assembly) | 1 | |
| 5 | 41-3795 | HARNESS - heater temperature sensor (assembly) | 1 | |
| 6 | 41-3796 | HARNESS - compressor supply (assembly) | 1 | |
| 7 | 41-3797 | HARNESS - unit control (assembly) | 1 | |
| 8 | 41-3822 | CONNECTOR (10-pin) | 1 | |
| 9 | 41-3815 | CONNECTOR (2-pin) | 1 | |
| 10 | 41-3421 | CONNECTOR (3-pin) | 1 | |
| 11 | 41-3798 | HARNESS - temperature sensors (assembly) | 1 | |
| 12 | 41-3821 | CONNECTOR (8-pin) | 1 | |
| 13 | 44-9631 | CONNECTOR (3-pin, see 112D9) | 3 | |
| 44-9536 | WEDGE - connector (3-pin) | 3 | ||
| 14 | 44-9585 | CONNECTOR (2-pin, see 112D9) | 2 | |
| 44-9586 | WEDGE - connector (2-pin) | 2 | ||
| 15 | 41-3799 | HARNESS - ground (assembly) | 1 | |
| 16 | 40-974 | KIT - sensor (27 graded) | 2 | |
|
40-974 OEM | Датчик температуры калиброванный | 8 770 ₽ |
|
|
10-40-974 | Датчик температуры калиброванный | 3 500 ₽ |
|
| 44-9544 | RECEPTACLE (3-pin, see 112D9) | 2 |
