Установкa Thermo King схема THERMOGUARD TG VI – 156B3
Обновление от: 11/28/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 45-2425 | THERMOGUARD - TG VI | 1 | |
| 845-2425 | THERMOGUARD - TG VI (reman) | 1 | ||
| 2 | 91-9805 | FACEPLATE/OVERLAY - TG VI | 1 | |
| 3 | 40-1080 | KIT - eprom chip | 1 | |
| 4 | 33-2894 | GASKET - bezel | 2 | |
| 5 | 55-4580 | SCREW - microprocessor (1 in long) | 4 | |
| 55-4331 | SCREW - microprocessor (1.25 in long) | 2 | ||
| 55-2993 | LOCKWASHER | 6 | ||
| 55-2086 | FLATWASHER | 6 | ||
| 6 | 91-9303 | BEZEL | 1 | |
|
10-91-9303 | Панель | 11 860 ₽ |
|
| 7 | 91-9302 | COVER | 1 | |
| 8 | 91-8352 | SPRING | 2 | |
| 9 | 91-9216 | BLOCK - door latch | 1 |
