Установкa Thermo King схема REFRIGERATION COMPONENTS – 154A6
Обновление от: 8/5/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-679 | COMPRESSOR (1/2hp, 115V) | 1 | |
| 55-3089 | SCREW - compressor | 4 | ||
| 55-2958 | FLATWASHER | 4 | ||
| 305-1440 | WASHER | 4 | ||
| 99-1899 | SPACER - compressor | 4 | ||
| 55-4967 | NUT | 4 | ||
| 2 | 66-9753 | TUBE - suction (bulkhead to compressor) | 1 | |
| 3 | 55-6389 | CLAMP - tube | 1 | |
| 55-3121 | SCREW - clamp | 1 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-4953 | NUT | 1 | ||
| 4 | 66-9754 | TUBE - discharge (compressor to condenser) | 1 | |
| 66-8327 | FITTING - saddle | 1 | ||
| 5 | 91-2686 | CLAMP - tube | 1 | |
| 55-3121 | SCREW - clamp | 1 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-4953 | NUT | 1 | ||
| 6 | 41-3146 | SWITCH - hpco | 1 | |
| 44-5838 | CONNECTOR - tower (2-pin) | 1 | ||
| 203-393 | SEALER - thread | A/R | ||
| 7 | 67-1586 | COIL - condenser | 1 | |
| 55-2957 | SCREW - coil | 3 | ||
| 55-1800 | LOCKWASHER | 3 | ||
| 55-2086 | FLATWASHER | 3 | ||
| 8 | 55-3059 | NUT - captive (1/4-20) | 4 | |
| 55-4526 | NUT - captive (10-32) | 4 | ||
| 9 | 55-9284 | SPACER - coil | 1 | |
| 10 | 66-9750 | TUBE - liquid (condenser to receiver tank) | 1 | |
| 61-2599 | FITTING - saddle | 1 | ||
| 11 | 66-7392 | VALVE - high pressure relief | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 12 | 33-1015 | O-RING | 1 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 13 | 55-6388 | CLAMP - tube | 2 | |
| 55-3462 | SCREW - clamp | 1 | ||
|
20-55-3462 | Болт | 600 ₽ |
|
| 55-2086 | FLATWASHER | 2 | ||
| 55-4953 | NUT | 1 | ||
| 14 | 67-2325 | TANK - receiver | 1 | |
| 55-4955 | NUT - tank | 2 | ||
| 55-7531 | FLATWASHER | 2 | ||
| 15 | 55-1804 | BUSHING (1/2 ftg, 3/8 sld) | 2 | |
| 16 | 66-9751 | TUBE - receiver tank to dehydrator | 1 | |
| 17 | 66-9748 | DEHYDRATOR | 1 | |
| 18 | 55-2141 | HANGER - dehydrator | 1 | |
| 55-4953 | NUT | 2 | ||
| 55-1587 | SCREW - hanger | 2 | ||
| 55-3462 | SCREW - dehydrator | 1 | ||
|
|
20-55-3462 | Болт | 600 ₽ |
|
| 55-2086 | FLATWASHER | 4 | ||
| 19 | 66-9752 | TUBE - dehydrator to bulkhead | 1 | |
| 20 | 41-3145 | SWITCH - dual pressure (see 154A7, before 9/00) | 1 | |
| 21 | 41-4781 | SWITCH - dual pressure (see 154A7, 9/00 & after) | 1 | |
| 22 | 55-308 | ELBOW | 2 | |
| 203-393 | SEALER - thread | A/R | ||
| 23 | 55-9285 | COUPLING (5/8 sld, 3/8 sld) | 1 | |
| 24 | 55-2865 | COUPLING (1/2 sld, 3/8 sld) | 1 | |
| 25 | 66-9749 | TUBE - gauge (before 9/00) | 2 | |
| 55-2332 | BANDWRAP | 5 |
