Установкa Thermo King схема COMPRESSOR GROUP (MODULOAD) – 153E1
Обновление от: 4/28/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 8102-716 | COMPRESSOR (Delta Reed) (365-53672-00) | 1 | |
| 2 | 503-284 | GASKET - valve plate (K28-70431-00) | 1 | |
| 33-3513 | GASKET - valve plate (Delta reed compressor only) | 1 | ||
| 3 | 33-2218 | GASKET - cylinder head (K28-70373-00) | 1 | |
| 4 | 502-215 | VALVE - solenoid (unload) (K29-51754-00) | 3 | |
| 5 | 504-790 | COIL - moduload (K25-50005-00) | 3 | |
| 6 | 506-287 | VALVE - repair (K26-72426-00) | 1 | |
| 7 | 503-231 | GASKET - solenoid valve (unload) (K28-51755-00) | 3 | |
| 8 | 503-308 | VALVE - plate (K29-70454-00) | 1 | |
| 22-1162 | KIT - valve plate (Delta Reed compressors only) | 1 | ||
| 9 | 505-631 | BOLT - control valve & cover plate (K21-70413-01) | 2 | |
| 10 | 509-472 | COVER - plate (060-54987-00) | 1 | |
| 11 | 503-269 | GASKET - cover plate (K28-58832-00) | 1 | |
| 12 | 509-1025 | SPACER - plate (K29-70445-00) | 1 | |
| 13 | 503-287 | GASKET - spacer plate (K28-70444-00) | 1 | |
| 14 | 505-264 | BOLT - cylinder head (K21-70413-05) | 11 | |
| 15 | 507-129 | SPACER - seal (K28-70443-00) | 3 | |
| 16 | 507-128 | SPACER - seal (K28-70442-00) | 3 | |
| 17 | 505-635 | PLUG (K23-51705-01) | 1 | |
| 18 | 505-266 | PIN - dowel (K21-70428-00) | 2 | |
| 19 | 505-268 | PIN - dowel (K21-70430-00) | 6 | |
| 20 | 502-220 | CYLINDER - head (K29-70441-00) | 1 | |
| 21 | 55-9037 | SCREW - compressor (50 mm) (K21-50227-50) | 2 | |
| 505-601 | SCREW - compressor (40 mm) (K21-50227-40) | 2 | ||
| 55-8912 | FLATWASHER (K21-50411-12) | 4 | ||
| 55-8913 | WASHER (K21-50401-12) | 2 | ||
| 55-8992 | NUT (K21-50100-12) | 4 | ||
| 22 | 22-1186 | ADAPTER - discharge (360-53562-00) | 1 | |
| 505-596 | SCREW - adapter (K21-58780-30) | 2 | ||
| 55-8913 | LOCKWASHER (K21-50401-12) | 4 | ||
| 23 | 33-2548 | GASKET - adapter (K28-50062-00) | 2 | |
| 24 | 33-981 | GASKET - valve (K28-04836-00) | 1 | |
| 25 | 41-3250 | SWITCH - hpco (K25-72456-00) | 1 | |
| 26 | 66-9150 | VALVE - discharge (K22-52019-00) | 1 | |
| 27 | 66-9873 | ADAPTER - service (high side) (K23-52185-01) | 1 | |
| 28 | 506-162 | CAP - discharge valve (K22-06971-00) | 1 | |
| 29 | 66-9149 | VALVE - suction (K22-50004-00) | 1 | |
| 30 | 66-3015 | CAP - suction valve (K22-50005-00) | 1 | |
| P-17-10806-10 | Крышка сервисного клапана, латунь, 05K/05G/06D | 3 000 ₽ |
|
|
|
10-66-3015 | Крышка сервисного клапана, латунь, X426/430/640 | 3 000 ₽ |
|
| 31 | 503-230 | GASKET - suction (K28-51696-00) | 1 | |
| 32 | 505-299 | ELBOW (K23-13049-03) | 1 | |
| 33 | 505-336 | ADAPTER - service (lowside) (K23-52185-02) | 1 | |
| 34 | 509-1153 | LABEL - compressor oil (K35-52041-00) | 1 | |
| 35 | 22-398 | SIGHT GLASS - oil (K29-51697-00) | 1 | |
| 36 | 41-2716 | WIRING - compressor (360-80161-40) | 1 | |
| 37 | 504-887 | FITTING - harness (K25-51784-21) | 1 |
