Установкa Thermo King схема ELECTRICAL COMPONENTS – 152G13
Обновление от: 10/11/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-3002 | HARNESS - sensor (before 3/01) | 1 | |
| 41-4343 | HARNESS - sensor (after 2/01) | 1 | ||
| 2 | 40-975 | SENSOR - temperature (ungraded) | 1 | |
|
40-975 OEM | Датчик температуры к-т, некалиброванный | 10 310 ₽ |
|
|
10-40-975 | Датчик температуры к-т, некалиброванный | 4 660 ₽ |
|
| 55-6388 | CLAMP - sensor | 1 | ||
| 55-3121 | SCREW - clamp | 1 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-4953 | NUT | 1 | ||
| 3 | 44-9181 | SOLENOID - fuel (see 106A1) | 1 | |
|
10-44-9181 | Соленоид оборотов двигателя | 22 340 ₽ |
|
| 10-41-1566 | Соленоид оборотов двигателя в сборе | 19 600 ₽ |
|
|
|
PP-44-9181 | Соленоид оборотов двигателя в сборе | 6 870 ₽ |
|
| 4 | 41-3001 | HARNESS - engine (before 5/00) | 1 | |
| 41-3663 | HARNESS - engine (5/00 to 3/01) | 1 | ||
| 41-4345 | HARNESS - engine (after 2/01) | 1 | ||
| 5 | 41-6539 | SENSOR - water temperature | 1 | |
|
10-41-6539 | Датчик температуры двигателя Yanmar 370 / 374 / 376 / 395 / 482 / 486 / 486V | 8 970 ₽ |
|
|
PP-41-6539 | Датчик температуры двигателя Yanmar 370 / 374 / 376 / 395 / 482 / 486 / 486V | 2 720 ₽ |
|
| 6 | 44-8244 | FUSE LINK (see 152G6, see note) | 1 | |
|
10-44-8244 | Провод предохранителя | 1 790 ₽ |
|
| 40-805 | KIT - battery fuse | 1 | ||
|
10-40-805 | Корпус предохранителя (60 ампер) | 7 860 ₽ |
|
| 41-3666 | FUSE (60 amp) | 1 | ||
| 7 | 41-6582 | GLOW PLUG | 3 | |
|
10-41-6582 | Свеча накаливания, Yanmar 249 / 366 / 374 / 388 / 395 | 2 470 ₽ |
|
|
10-42-916 | Свеча накаливания, Yanmar 370 / 376 | 2 340 ₽ |
|
| PP-41-6582 | Свеча накаливания, Yanmar 249 / 366 / 374 / 388 / 395 | 1 190 ₽ |
|
|
| PP-42-916 | Свеча накаливания, Yanmar 370 / 376 | 1 190 ₽ |
|
|
| 44-7129 | CONNECTOR - glow plug | 1 | ||
| 8 | 41-402 | SWITCH - oil level | 1 | |
|
41-402 OEM | Датчик уровня масла | 10 090 ₽ |
|
|
10-41-402 | Датчик уровня масла | 6 190 ₽ |
|
| 9 | 44-8883 | SENSOR - oil pressure transducer (see 136D7) | 1 | |
|
10-44-8883 | Сенсор давления масла, SB/SB-III/SMX-II/SL/SLe/TS-Series (SR) | 9 810 ₽ |
|
|
PP-44-8883 | Сенсор давления масла, SB/SB-III/SMX-II/SL/SLe/TS-Series (SR) | 2 930 ₽ |
|
| 10 | 44-9298 | SENSOR - rpm | 1 | |
|
10-44-9298 | Датчик оборотов двигателя | 14 400 ₽ |
|
|
PP-44-9298 | Датчик оборотов двигателя | 3 310 ₽ |
|
| 11 | 45-1718 | STARTER (see 132A8) | 1 | |
|
10-45-1718 | Стартер, Yanmar 366 / 374 / 388 / 395 | 12 860 ₽ |
|
| 45-2326 | STARTER (standard life plus) | 1 | ||
| 12 | 41-3845 | SWITCH - hpco | 1 | |
| 41-3845 OEM | Выключатель HPCO, KD-II/MD-II/RD-II/MD-XXX / T/TS-Series | 10 040 ₽ |
|
|
|
PP-41-3847 | Выключатель HPCO, KD-II/MD-II/RD-II/MD-XXX / T/TS-Series | 3 080 ₽ |
|
| 13 | 41-5246 | SWITCH - lpco | 1 | |
| 14 | 66-8560 | VALVE - pilot solenoid (see 152G11, 169D2) | 1 | |
| 66-8560 OEM | Пилот соленоид с катушкой 12V, KD/MD/RD/TD-II TS/XDS/SL/SLe/SLX/SLXe | 38 690 ₽ |
|
|
|
10-66-8560 | Пилот соленоид с катушкой 12V, KD/MD/RD/TD-II TS/XDS/SL/SLe/SLX/SLXe | 31 100 ₽ |
|
|
PP-61-8939 | Пилот соленоид с катушкой 12V, KD/MD/RD/TD-II TS/XDS/SL/SLe/SLX/SLXe | 8 380 ₽ |
|
| 15 | 61-283 | VALVE - solenoid (TherMax, see 138A11) | 1 | |
| 55-3029 | SCREW - valve | 2 | ||
| 55-3800 | LOCKWASHER | 2 | ||
| 55-2201 | FLATWASHER | 2 | ||
| 16 | 41-2194 | ALTERNATOR (23 amp, model EA, see 133B6) | 1 | |
|
10-41-2194 | Генератор 23A, KD/MD/RD/TD-II / TS / SB-II/III | 19 720 ₽ |
|
| 17 | 41-2303 | HARNESS - alternator | 1 | |
| 18 | 66-8989 | SWITCH - air pressure (see 144F10) | 1 | |
| 19 | 104-699 | MOTOR - electric (12 hp) | 1 | |
| 104-700 | MOTOR - electric (10 hp) | 1 | ||
| 41-1105 | SLEEVE - crimp | 5 | ||
| 44-6646 | CAP - crimp sleeve | 5 | ||
| 20 | 41-4474 | HARNESS - switch (on/off) | 1 | |
|
10-41-4474 | Выключатель и проводкой | 9 260 ₽ |
|
| 21 | 44-6534 | SENSOR - water level | 2 | |
|
10-44-6534 | Сенсор радиатора | 8 830 ₽ |
|
| 22 | 41-2308 | HARNESS - remote cab box | 1 | |
| 23 | 45-1866 | BOX - cab remote (see 136G7) | 1 | |
| 24 | 41-2999 | HARNESS - condenser (before 5/00) | 1 | |
| 41-3662 | HARNESS - condenser (5/00 to 3/01) | 1 | ||
| 41-4344 | HARNESS - condenser (after 2/01) | 1 | ||
| 41-5170 | HARNESS - main (7/02 & after, replaces condenser & engine harness) | 1 | ||
| 25 | NSS | BOX - remote light (optional, see 136G2) | 1 | |
| 26 | 99-9501 | BOX - power receptacle (TSA, see 124G14) | 1 | |
| 92-1948 | BOX - power receptacle (EMEIA, see 197G2) | 1 | ||
| 27 | 41-2590 | THERMOMETER - digital LED (F, optional) | 1 | |
| 41-2591 | THERMOMETER - digital LED (C, optional) | 1 | ||
| 55-6390 | SCREW - thermometer | 3 | ||
| 55-3014 | LOCKWASHER | 3 | ||
| 55-2999 | NUT | 3 | ||
| 28 | 44-7674 | SENSOR - thermometer | 1 | |
| 55-2239 | CLAMP - sensor | 1 | ||
| 29 | 41-1941 | CABLE - heater | 1 | |
| 33-572 | GROMMET (3/4 id, 1/8 groove) | 1 | ||
| 33-432 | GROMMET (3/4 id, 1/16 groove) | 1 | ||
| 30 | 44-7354 | BOX - junction | 1 | |
| 55-2269 | SCREW - box | 2 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-4560 | NUT | 2 | ||
| 31 | 45-1374 | HEATER | 3 | |
| 32 | 91-240 | RETAINER - heater | 12 | |
| 33 | 44-2823 | SOLENOID - damper (see 131B10) | 1 | |
|
10-44-2823 | Соленоид оборотов двигателя | 5 640 ₽ |
|
| 34 | 41-2313 | HARNESS - damper solenoid | 1 | |
| 35 | 40-974 | KIT - sensor (graded) | 2 | |
|
40-974 OEM | Датчик температуры к-т, калиброванный | 25 620 ₽ |
|
|
10-40-974 | Датчик температуры к-т, калиброванный | 4 660 ₽ |
|
| 55-2239 | CLAMP - sensor | 1 | ||
| 55-2991 | SCREW - clamp | 1 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-4560 | NUT | 1 | ||
| 36 | 41-7059 | PUMP - fuel (12V) | 1 | |
|
30-66840-00 OEM | Топливный насос подкачки | 22 850 ₽ |
|
|
US-41-7059 | Топливный насос подкачки | 19 340 ₽ |
|
| P-30-01108-12 | Топливный насос подкачки, HP | 9 870 ₽ |
|
|
|
10-41-7059-HP | Топливный насос подкачки, HP | 9 460 ₽ |
|
| 10-376 | KIT - filter (diesel) | 1 | ||
| 10-378 | KIT - bowl & gasket | 1 | ||
| 33-4256 | GASKET - bowl to body | 1 | ||
| 10-273 | KIT - filter (for 41-2640 fuel pump) | 1 | ||
| 33-1676 | GASKET - fuel pump (for 41-2638 fuel pump) | 1 | ||
| 37 | 41-3664 | HARNESS - fuel pump | 1 |
