Установкa Thermo King схема T-1000R TSA & EMEIA REFERENCE SHEET – 14U95
Обновление от: 1/31/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 901406 | System T-1000R 30 TSA | 1/10 | ||
| 901427 | System T-1000R 30 EMEIA | 8/11 | ||
| 901407 | System T-1000R 50 TSA 230/3/60 | 6/12 | ||
| 901408 | System T-1000R 50 TSA 460/3/60 | 8/11 | ||
| 901428 | System T-1000R 50 EMEIA 220/3/50 | 8/11 | ||
| 901429 | System T-1000R 50 EMEIA 230/3/60 | 4/12 | ||
| 088462 | T-1000R 30 SR TSA | 1/10 | ||
| 088491 | T-1000R 30 SR EMEIA | 8/11 | ||
| 088486 | T-1000R 50 SR 230/3/60 TSA | 6/12 | ||
| 088487 | T-1000R 50 SR 460/3/60 TSA | 8/11 | ||
| 088503 | T-1000R 50 EMEIA 220/3/50 | 8/11 | ||
| 088504 | T-1000R 50 EMEIA 230/3/60 | 4/12 | ||
| 097663 | T-1000R 50 EMEIA 400/3/50 | 11/09 | ||
| 088239 | Battery Box | 4/12 | ||
| 088259 | DAS datalogger EMEIA | 4/12 | ||
| 088258 | DAS datalogger TSA | 1/13 | ||
| 088267 | EPDM Engine Hoses | 8/11 | ||
| 088275 | Evaporator Covers | 1/13 | ||
| 088292 | Heaters | 6/12 | ||
| 088293 | Remote HMI Display | 1/10 | ||
| 088294 | Remote HMI Display | 1/10 | ||
| 088296 | Thermometer F | 1/13 | ||
| 088297 | Thermometer C | 1/13 | ||
| 088286 | Suction Tubing Mechanical Throttling Valve | 8/11 | ||
| 088300 | DAS-TracKing (EU SIM) | 4/12 | ||
| 088301 | DAS-TracKing (UK SIM) | 4/12 | ||
| 088302 | DAS-TracKing (TSA) | 1/13 | ||
| 088319 | Top Screen | 1/13 | ||
| 088866 | WHISPER Plus | 1/13 | ||
| 088321 | Remote HMI Display | 8/11 | ||
| 088325 | Remote Box HMI | 1/13 | ||
| 088333 | Chrome Grille | 1/13 | ||
| 088334 | Silicone Hoses | 6/12 | ||
| 088562 | Engine Block Heater | 1/13 | ||
| 088663 | T-1000R 50 SR 400/3/50 EMEIA | 4/10 | ||
| 088836 | Screen & Fan | 8/11 | ||
| 088837 | Remote Service Watch Port | 1/13 | ||
| 088867 | Ldb Top Screen | 1/13 | ||
| 088877 | Extended Harnesses | 1/13 | ||
| 088891 | Premium HMI Extended harness | 1/13 | ||
| 088899 | Standard HMI Extended harness | 1/13 | ||
| 088868 | EON Battery | 4/12 | ||
| 097622 | Control Box 30SR TSA | 8/11 | ||
| 097634 | 230/3/60 TSA | 1/10 | ||
| 097637 | 460/3/60 TSA | 8/11 | ||
| 097635 | Control Box 400/3/50 EMEIA | 4/10 | ||
| 097636 | Control Box 220V EMEIA | 4/10 | ||
| 097638 | Control Box 230/3/60 EMEIA | 4/10 | ||
| 097679 | 380/3/50 4-Pin Receptacle | 4/12 | ||
| 097739 | Premium HMI | 1/13 | ||
| 097699 | Oil Drain Valve | 1/13 | ||
| 097713 | 230/3/50 4-Pin Receptacle | 4/12 | ||
| 097735 | CONTROLLER - HMI (premium) | 4/12 | ||
| 700248 | Door Switch | 1/13 | ||
| 700307 | Door Switch - 3 wire | 8/11 | ||
| 700533 | Door Switch | 8/11 | ||
| 700534 | Door Switch | 1/13 | ||
| 700955 | Hose Management (straight) | 1/13 | ||
| 700956 | Hose Management (curved) | 1/13 | ||
| 701299 | Remote Status Light Kit | 1/13 | ||
| 701468 | Fuel Tank 30 Gal | 1/13 | ||
| 701651 | Flush Mount Controller TSA | 6/12 | ||
| 701652 | Flush Mount Controller EMEIA | 11/09 | ||
| 701288 | Remote Status Light Kit | 8/11 | ||
| 718350 | DAS Sensor 10 ft | 1/13 | ||
| 718351 | DAS Sensor 20 ft | 1/13 | ||
| 718352 | DAS Sensor 40 ft | 1/13 | ||
| 719182 | Hose Management Kit | 6/12 | ||
| 702177 | Snow Cover | 1/13 | ||
| 800373 | Installation Kit EMEIA | 1/13 | ||
| 800374 | Installation Kit EMEIA | 4/12 | ||
| 800213 | Battery Box EMEIA | 8/11 | ||
| 810044 | Battery Box TAS | 1/13 |
