Установкa Thermo King схема T1-M173 REFERENCE SHEET – 14U6
Обновление от: 4/2/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 900906 | System - T1-M173 R134a | 3/09 | ||
| 600293 | T1-M173 R134a | 3/09 | ||
| 006445 | T1 Generic | 3/09 | ||
| 006448 | T1 Reliance Motor | 3/09 | ||
| 006451 | T1 Display Panel w/o panel | 3/09 | ||
| 006462 | T1 Evaporator Heater Connections | 3/09 | ||
| 006464 | T1 Evaporator Heater Hose - EPDM | 3/09 | ||
| 006465 | T1 Refrigeration w/o Driver Air Fitting | 3/09 | ||
| 006470 | T1 Air Filter Woven | 3/09 | ||
| 006544 | T1 Refrigeration Fittings | 3/09 | ||
| 006558 | T1 Software w/o Loaders | 3/09 | ||
| 006899 | T1 Panel/Closure | 3/09 | ||
| 007002 | T1 R134a S616 | 3/09 | ||
| 007004 | T1 Evaporator Coil | 3/09 | ||
| 007006 | T1 Condenser Coil | 3/09 | ||
| 007008 | T1 Pressure Gauges | 3/09 | ||
| 007406 | T1 Positive Stud | 3/09 | ||
| 007330 | T1 Rear Access Panel | 3/09 | ||
| 700155 | Compressor Kit - S616 R134a | 3/09 | ||
| 800343 | Installation Kit | 3/09 |
