Установкa Thermo King схема FANS, PULLEYS & BELTS (FM KIT 712706) – 148C2
Обновление от: 11/28/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 78-867 | FAN - evaporator | 2 | |
| 2 | 91-3915 | BOLTPLATE - fanshaft | 2 | |
| 55-7344 | NUT - fanshaft | 8 | ||
| 55-6999 | FLATWASHER | 8 | ||
| 3 | 78-871 | FANSHAFT - assembly (see 106A3) | 2 | |
| 4 | 55-457 | KEY - fanshaft | 4 | |
| 5 | 77-2080 | PULLEY - fan drive | 1 | |
| 6 | 77-2081 | PULLEY - fan | 1 | |
| 55-7343 | SCREW - pulley | 4 | ||
| 55-7342 | LOCKWASHER | 4 | ||
| 55-6988 | FLATWASHER | 4 | ||
| 7 | 77-2086 | PULLEY - idler (see 141B11) | 1 | |
| 8 | 78-626 | BELT - fan & alternator | 1 | |
| 10-78-626 | Ремень вентилятора и генератора, LND | 4 940 ₽ |
|
|
| 9 | 45-2254 | ALTERNATOR (37 amp, see 208F4) | 1 | |
|
10-45-2589 | Генератор 37A, SB-XXX/SMX/SMX-II/SL/SLe SB-II/III | 13 870 ₽ |
|
|
10-41-6780 | Генератор 37A, SB-XXX/SMX/SMX-II/SL/SLe SB-II/III | 13 870 ₽ |
|
| 41-8461 | ALTERNATOR (37 amp, Standard Life Plus) | 1 | ||
|
|
10-45-2589 | Генератор 37A, SB-XXX/SMX/SMX-II/SL/SLe SB-II/III | 13 870 ₽ |
|
|
|
10-41-6780 | Генератор 37A, SB-XXX/SMX/SMX-II/SL/SLe SB-II/III | 13 870 ₽ |
|
| 845-2254 | ALTERNATOR (37 amp, remanufactured) | 1 | ||
| 10 | 91-8087 | MOUNT - alternator (see 141B2) | 1 | |
| 11 | 78-863 | FAN & HUB - assembly | 2 | |
| 55-7343 | SCREW - hub to shaft | 4 | ||
| 55-7342 | LOCKWASHER | 4 | ||
| 55-7085 | FLATWASHER | 4 | ||
| 12 | 77-2083 | PULLEY - idler (see 141B11) | 1 | |
| 13 | 78-1104 | BELT - fan drive | 1 | |
| 14 | 55-5871 | WASHER - special | 4 | |
| 15 | 77-2433 | PULLEY - idler (see 148C7) | 1 | |
| 16 | 78-862 | ORIFICE - condenser fan (right) | 1 | |
| 17 | 78-861 | ORIFICE - condenser fan (left) | 1 | |
| 55-6994 | SCREW - orifice | 21 | ||
| 55-3045 | WASHER - dome | 21 | ||
| 18 | 91-8794 | BRACKET - idler | 1 | |
| 91-3917 | BOLTSTRIP | 3 | ||
| 55-7344 | NUT - bracket | 6 | ||
| 55-6999 | FLATWASHER | 6 |
