Установкa Thermo King схема HARNESS ASSEMBLY - CONTACTOR – 145B10
Обновление от: 1/9/98
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-2458 | HARNESS - assembly | 1 | |
| 2 | 41-2319 | CONNECTOR - receptacle (12-pin) | 1 | |
| 3 | 41-182 | TERMINAL - pin | 9 | |
| 4 | 41-438 | TERMINAL - forked (blue) | 5 | |
| 41-280 | TERMINAL - forked (red) | 8 |
