Установкa Thermo King схема CONTROL BOX – 145B1
Обновление от: 1/13/99
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-5012 | BOX - control | 1 | |
| 55-2977 | SCREW - box | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 2 | 55-2788 | FITTING - barb | 4 | |
| 55-5018 | NUT - fitting | 4 | ||
| 3 | 55-3000 | SCREW - ground | 4 | |
| 55-2001 | FLATWASHER | 8 | ||
| 55-3008 | WASHER - sealing | 4 | ||
| 55-2965 | NUT | 8 | ||
| 55-2996 | LOCKWASHER | 8 | ||
| 4 | 91-8560 | BRACKET - box | 1 | |
| 55-4953 | NUT - bracket | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 5 | 99-8149 | LATCH - door | 1 | |
| 6 | 55-4953 | NUT | 1 | |
| 55-2086 | FLATWASHER | 3 | ||
| 55-2363 | LOCKWASHER | 1 | ||
| 7 | 99-8994 | SPACER - tube | 1 | |
| 8 | 99-8993 | BRACKET - latch | 1 | |
| 9 | 55-2957 | SCREW - latch | 1 | |
| 55-3000 | SCREW - bracket | 2 | ||
| 55-3008 | WASHER - sealing | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-4560 | NUT | 2 | ||
| 10 | 55-5257 | CONNECTOR - liquid tite | 1 | |
| 11 | 55-5111 | CONNECTOR - liquid tite | 2 | |
| 12 | 55-5885 | CONNECTOR - liquid tite | 1 | |
| 13 | 91-8561 | RAIL - contactor | 2 | |
| 55-9016 | SCREW - rail | 8 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 55-1800 | LOCKWASHER | 8 | ||
| 14 | 44-8812 | CONTACTOR | 7 | |
| 55-3025 | SCREW - contactor & module | 10 | ||
| 55-2001 | FLATWASHER | 10 | ||
| 55-2964 | LOCKWASHER | 10 | ||
| 15 | 44-8813 | INTERLOCK - contactor | 2 | |
| 16 | 45-1733 | MODULE - current sense | 1 | |
| 17 | 91-7540 | PANEL - circuit breaker (see 145B2) | 1 | |
| 18 | 44-6822 | SOCKET - remote monitor (see 145B3) | 1 | |
| 19 | 44-6560 | SWITCH - toggle (4pdt) | 1 | |
| 20 | 44-739 | BOOT - switch | 1 | |
| 21 | 41-2129 | TRANSFORMER | 1 | |
| 44-3710 | JUMPER - transformer | 1 | ||
| 55-3842 | SCREW - transformer | 4 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-2964 | LOCKWASHER | 4 | ||
| 22 | 45-1711 | MODULE - mP-D output (see 145B8) | 1 | |
| 55-4148 | SCREW - module | 4 | ||
| 55-2996 | LOCKWASHER | 4 | ||
| 23 | 44-5114 | POST - binding (thermistor lead) | 1 | |
| 24 | 204-209 | LEAD - thermistor | 1 | |
| 25 | 41-1755 | BOARD - pc (rectifier/regulator, see 145B4) | 1 | |
| 26 | 41-2404 | CONNECTOR - receptacle (super harness, 37-pin) | 1 | |
| 27 | 41-2403 | CONNECTOR - receptacle (analog harness, see 145B5) | 1 | |
| 55-2868 | SCREW - receptacle | 8 | ||
| 55-3013 | FLATWASHER | 16 | ||
| 55-5754 | NUT | 8 | ||
| 33-2984 | GASKET - dual connector | 1 | ||
| 28 | 91-7538 | COVER - control box (see 145A14) | 1 |
