Установкa Thermo King схема OIL DRAIN HOSE GROUP – 141B5
Обновление от: 5/19/97
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 11-3807 | CLIP - oil hose | 1 | |
| 55-7041 | SCREW - clip | 1 | ||
| 55-4665 | FLATWASHER | 1 | ||
| 55-7011 | NUT | 1 | ||
| 2 | 11-6177 | HOSE - oil drain | 1 | |
|
10-11-6177 | Трубка масляная сливная (Yanmar) | 3 670 ₽ |
|
| 3 | 55-3229 | CAP - pipe | 1 |
