Установкa Thermo King схема SOLENOID PANEL GROUP – 140G1
Обновление от: 5/29/01
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-8069 | PANEL - solenoid | 1 | |
| 55-7710 | INSERT | 8 | ||
| 55-2977 | SCREW - panel | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 2 | 41-3987 | SOLENOID - assembly | 4 | |
| 55-3018 | SCREW - solenoid | 8 | ||
|
20-55-3018 | Болт | 540 ₽ |
|
| 55-2086 | FLATWASHER | 12 | ||
| 55-2993 | LOCKWASHER | 8 | ||
| 3 | 44-7472 | STRAP - jumper | 2 | |
| 4 | 44-6007 | DIODE | 4 |
