Установкa Thermo King схема SB-210+ 30 & 50 REFERENCE SHEET – 13U28
Обновление от: 7/12/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 900839 | System - SB-210+ 30 | 5/08 | ||
| 900840 | System - SB-210+ 50 | 9/09 | ||
| 069002 | SB-210+ 30 | 5/08 | ||
| 069003 | SB-210+ 50 | 9/09 | ||
| 048699 | 200V Motor | 9/09 | ||
| 002016 | Special Paint | 9/09 | ||
| 002020 | Chrome Grille | 9/09 | ||
| 002030 | 65 Amp Alternator SB-210+ 50 | 9/09 | ||
| 002065 | Vinyl Dip Coil | 9/09 | ||
| 002068 | Fresh Air Exchanger | 5/08 | ||
| 002070 | Fresh Air Exchanger | 5/08 | ||
| 002079 | Japan Motor | 5/08 | ||
| 002128 | SB-210 ETV | 5/08 | ||
| 002157 | 460V Motor | 5/08 | ||
| 002208 | Fuel Heater - Tier 2 | 5/08 | ||
| 002215 | Fuel Heater - Tier 2 | 5/08 | ||
| 002236 | Tapered Battery Cables | 5/08 | ||
| 002242 | Fuel Tank - 30 Gallon AL 22 Dia | 8/09 | ||
| 002246 | Fuel Tank - 50 Gallon AL 18 Dia | 5/08 | ||
| 002725 | ETV SB-210 50 | 5/08 | ||
| 002726 | iBox 3rd Party 2-Way | 8/09 | ||
| 048332 | Compound Gauge | 5/08 | ||
| 048660 | Alternator - 65 Amp | 5/08 | ||
| 048678 | Frost Plug Heater | 5/08 | ||
| 048701 | Fuel Tank - 30 Gallon AL 18 Dia | 5/08 | ||
| 069006 | Fuel Tank - 50 Gallon AL 22 Dia | 5/08 | ||
| 069007 | Fuel Tank - 50 Gallon AL 22 Dia | 5/08 | ||
| 069008 | Fuel Tank - 110 Gallon AL 22 Dia | 5/08 | ||
| 069009 | Fuel Tank - 50 Gallon AL 22 Dia | 5/08 | ||
| 069010 | Fuel Tank - 50 Gallon AL 22 Dia | 5/08 | ||
| 069011 | Fuel Tank - 120 Gallon AL 22 Dia | 5/08 | ||
| 069012 | Fuel Tank - 120 Gallon AL 22 Dia | 5/08 | ||
| 069013 | Fuel Tank - 75 Gallon AL 22 Dia | 5/08 | ||
| 069016 | Fuel Tank - 120 Gallon AL 22 Dia | 5/08 | ||
| 069017 | Fuel Tank - 120 Gallon AL 22 Dia | 5/08 | ||
| 069019 | Fuel Tank - 50 Gallon AL 22 Dia | 5/08 | ||
| 069020 | Fuel Tank - 454L Steel | 5/08 | ||
| 069022 | Special Paint | 5/08 | ||
| 069027 | Special Paint | 5/08 | ||
| 069033 | Special Paint | 5/08 | ||
| 069041 | Special Paint | 9/09 | ||
| 069042 | Chrome Grille | 5/08 | ||
| 069043 | Special Paint | 5/08 | ||
| 069044 | Fuel Gauge Kit | 9/09 | ||
| 069048 | Fuel Tank - 50 Gallon AL 22 Dia | 9/09 | ||
| 069049 | Fuel Tank - 50 Gallon AL 22 Dia | 9/09 | ||
| 069050 | Fuel Tank - 110 Gallon AL 22 Dia | 9/09 | ||
| 069051 | Fuel Tank - 50 Gallon AL 22 Dia | 9/09 | ||
| 069052 | Fuel Tank - 50 Gallon AL 22 Dia | 9/09 | ||
| 069053 | Fuel Tank - 120 Gallon AL 22 Dia | 9/09 | ||
| 069054 | Fuel Tank - 120 Gallon AL 22 Dia | 9/09 | ||
| 069055 | Fuel Tank - 75 Gallon AL 22 Dia | 9/09 | ||
| 069057 | Fuel Tank - 120 Gallon AL 22 Dia | 9/09 | ||
| 069058 | Fuel Tank - 120 Gallon AL 22 Dia | 9/09 | ||
| 069059 | Fuel Tank - 50 Gallon AL 22 Dia | 9/09 | ||
| 069060 | Fuel Tank - 454L Steel | 9/09 | ||
| 069062 | 460/3/60 24 hp Motor | 9/09 | ||
| 069071 | 460/3/60 24 hp Motor, Remote Receptacle | 8/10 | ||
| 069067 | Remote Receptacle 230V | 8/10 | ||
| 069068 | Remote Receptacle 460V | 8/10 | ||
| 069069 | Oil Drain Quick Connect | 9/09 | ||
| 085398 | MDA | 9/09 | ||
| 700248 | ERC-1 | 5/08 | ||
| 700250 | Door Switch | 5/08 | ||
| 700252 | Flushmount Remote Controller | 5/08 | ||
| 700307 | Door Switch | 5/08 | ||
| 701288 | Status Display Lights | 5/08 | ||
| 701289 | Fuel Display | 9/09 | ||
| 701290 | Temperature Display | 9/09 | ||
| 701310 | Trac-King 2-Way SR-2 | 5/08 | ||
| 701336 | Status Display Lights Flush Mount | 5/08 | ||
| 701462 | Fuel Level Sensor | 5/08 | ||
| 701874 | GPRS Tracking | 9/09 | ||
| 701951 | Receptacle Kit 460V | 9/09 | ||
| 705782 | KIT Fuel Tank Bands | 9/09 | ||
| 720491 | HMI Sensor - 10 ft | 9/09 | ||
| 720492 | HMI Sensor - 20 ft | 9/09 | ||
| 720493 | HMI Sensor - 40 ft | 9/09 | ||
| 720494 | HMI Sensor - 60 ft | 9/09 | ||
| 720495 | HMI Sensor - 80 ft | 9/09 | ||
| 720718 | iBox SR-2 3rd Party | 9/09 | ||
| 720724 | Kit - RCOM II SR-2 | 9/09 | ||
| 808851 | Bolt - Kit | 9/09 | ||
| 811053 | Kit - Installation Box | 9/09 |
