Установкa Thermo King схема FANS, BELTS & PULLEYS GROUP (50s) – 139G1
Обновление от: 6/7/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 55-6146 | SCREW - fan (2-3/4 in) | 4 | |
| 55-790 | LOCKWASHER | 4 | ||
| 55-371 | FLATWASHER | 4 | ||
| 2 | 78-750 | FAN - condenser | 1 | |
| 3 | 77-2237 | BUSHING - taper | 1 | |
| 4 | 77-2253 | MOUNT - fan | 1 | |
| 5 | 77-2219 | PULLEY - fan | 1 | |
| 6 | 55-7801 | SCREW - pulley | 8 | |
| 55-402 | FLATWASHER | 8 | ||
| 7 | 55-457 | KEY - fan | 2 | |
| 8 | 78-707 | FANSHAFT - assembly (see 80F6) | 1 | |
| 55-129 | SCREW - fanshaft | 6 | ||
| 55-402 | FLATWASHER | 12 | ||
| 55-5078 | NUT | 6 | ||
| 9 | 99-3502 | PANEL - bulkhead | 1 | |
| 55-2683 | SCREW - panel | 11 | ||
| 55-2363 | LOCKWASHER | 11 | ||
| 55-2641 | FLATWASHER | 11 | ||
| 10 | 77-1771 | RING - blower | 1 | |
| 11 | 78-930 | WHEEL - blower | 1 | |
| 12 | 77-1592 | HUB - evaporator blower | 1 | |
| 55-3490 | SCREW - hub to blower | 4 | ||
| 55-2958 | FLATWASHER | 4 | ||
| 55-4954 | NUT | 4 | ||
| 55-8974 | SCREW - hub to shaft | 2 | ||
| 55-2959 | LOCKWASHER | 2 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 13 | 78-704 | ORIFICE - evaporator | 1 | |
| 14 | 55-2977 | SCREW - orifice to bulkhead | 4 | |
| 15 | 55-3045 | WASHER - dome | 4 | |
| 16 | 55-2904 | WASHER - special | A/R | |
| 17 | 91-1433 | PLATE - threaded | 1 | |
| 18 | 91-8346 | CAP - bottom | 1 | |
| 55-2991 | SCREW - cap | 3 | ||
| 55-2001 | FLATWASHER | 6 | ||
| 55-4560 | NUT | 3 | ||
| 19 | 77-2004 | PULLEY - idler (V-groove, see 80F11) | 1 | |
|
10-77-2004 | Ролик-успокоитель | 33 440 ₽ |
|
| 91-1778 | PLATE - threaded (pulley) | 1 | ||
| 20 | 77-2003 | PULLEY - idler (flat groove, see 80F11) | 1 | |
|
10-77-2003 | Ролик-успокоитель | 33 210 ₽ |
|
| 55-5749 | SPACER - lower idler | 1 | ||
| 99-9897 | CHANNEL - idler pulley | 1 | ||
| 21 | 78-1068 | BELT - fan drive | 1 | |
| 22 | 78-1131 | PULLEY - fan drive | 1 | |
| 23 | 77-2390 | PULLEY - damper (see 68D11) | 1 | |
| 24 | 77-2387 | SHIM - pulley (0.015 thk) | 1 | |
| 77-2386 | SHIM - pulley (0.036 thk) | 1 | ||
| 25 | 77-2385 | PULLEY - half section | 1 | |
| 26 | 55-8682 | SCREW - pulley | 4 | |
| 27 | 78-1011 | BELT - water pump | 1 | |
| 10-78-1011 | Ремень водяной помпы, SB-III после 96г. / SMX после 93г. | 3 100 ₽ |
|
|
| PP-78-1011 | Ремень водяной помпы, SB-III после 96г. / SMX после 93г. | 1 100 ₽ |
|
|
| 28 | 77-1345 | PULLEY - water pump | 1 | |
| 29 | 77-2066 | PULLEY - alternator | 1 | |
| 30 | 91-2676 | GUARD - belt (upper) | 1 | |
| 31 | 91-2675 | GUARD - belt (lower) | 1 | |
| 55-3021 | SCREW - guard | 6 | ||
| 55-1800 | LOCKWASHER | 6 | ||
| 55-2086 | FLATWASHER | 6 | ||
| 32 | 91-1416 | WASHER | 1 | |
| 33 | 107-341 | CLUTCH (see 125E4) | 1 | |
|
10-107-341 | Сцепление, SB-II/III / SMX/SMX-II | 100 300 ₽ |
|
| 34 | 78-1069 | BELT - clutch (set of 2) | 1 | |
| 35 | 78-843 | BELT - alternator | 1 | |
| 36 | 78-1071 | PULLEY - clutch | 1 | |
| 37 | 104-735 | MOTOR | 1 | |
| 38 | 91-1415 | CHANNEL - idler | 1 | |
| 39 | 204-427 | GAUGE - belt tension | 1 |
