Установкa Thermo King схема RAC 5.5 OIW REFERENCE SHEET – 12U60
Обновление от: 12/1/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 900710 | System - RAC 5.5. OIW | 10/08 | ||
| 096228 | Kit - Condenser RAC 4 | 10/08 | ||
| 096269 | Kit - Frame RAC | 10/08 | ||
| 096097 | Kit - Evaporator Coil R407C RAC | 10/08 | ||
| 096268 | Kit - Blower 200 mm | 10/08 | ||
| 096231 | Kit - Liquid Line RAC 4 | 10/08 | ||
| 096100 | Kit - Compressor II RAC | 10/08 | ||
| 096460 | Kit - Electric RAC OIW | 10/08 | ||
| 096455 | Kit - Cover Unit RAC | 10/08 | ||
| 096452 | Kit - Harnesses RAC 5.5 OIW | 10/08 | ||
| 096090 | Kit - Heater 5kW 400V | 10/08 | ||
| 096101 | Kit - Fluids R407C RAC | 10/08 | ||
| 096139 | Kit - Color LRV - RAC 7011 | 10/08 | ||
| 096453 | Kit - Documents RAC 5.5 OIW | 10/08 | ||
| 800052 | Kit - Installation RAC 5.5 | 10/08 | ||
| 096095 | Option - Lifting Kit RAC | 10/08 |
