Установкa Thermo King схема DOOR SWITCH KIT (OPTIONAL) – 129B12
Обновление от: 2/14/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-1452 | HARNESS - door switch (for connectors see 112D9) | 1 | |
| 2 | 44-5537 | SOCKET - relay | 1 | |
| 3 | 41-895 | RELAY - mini | 1 | |
|
30-41-895 | Реле | 1 650 ₽ |
|
| 55-3015 | SCREW - socket | 1 | ||
| 55-2001 | FLATWASHER | 1 | ||
| 4 | 41-685 | HARNESS - door switch (for connectors see 112D9) | 1 | |
| 5 | 55-2272 | CLAMP - harness | 30 | |
| 55-5640 | SCREW - clamp | 30 | ||
| 6 | 40-907 | KIT - door switch | 1 | |
| 55-8421 | SCREW - switch (1.0 in) | 2 | ||
| 51-1321 | SCREW - switch (0.75 in) | 2 | ||
| 55-2001 | FLATWASHER | 4 |
