Установкa Thermo King схема COMPRESSOR GROUP ASSEMBLY – 128G6
Обновление от: 1/24/01
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-476 | COMPRESSOR - X214 (see 107E2) | 1 | |
| 2 | 77-2256 | PULLEY - compressor (R12, R134a) | 1 | |
| 3 | 77-2537 | BUSHING | 1 | |
| 70-184 | KIT - screws & washers | 1 | ||
| 4 | 55-9024 | KEY | 1 | |
|
10-55-9024 | Шпонка коленвала, X418/426/430 | 590 ₽ |
|
| 5 | 41-3846 | SWITCH - hpco (450 psi) | 1 | |
| 6 | 44-8199 | SWITCH - hpco (200 psi) | 1 | |
| 7 | 11-5513 | VALVE - port | 1 | |
| 8 | 33-768 | GASKET - flare | 1 | |
| 9 | 55-1983 | CAP - flare | 5 | |
| 10 | 33-2805 | GASKET - discharge valve | 2 | |
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 11 | 22-188 | VALVE - discharge | 1 | |
|
10-22-188 | Клапан, Discharge | 8 260 ₽ |
|
| 12 | 55-581 | GASKET - cap | 1 | |
| 13 | 66-343 | CAP - valve | 1 | |
| 14 | 11-2886 | VALVE (Schrader) | 1 | |
| 15 | 11-7777 | CORE - valve | 1 | |
| 16 | 55-5672 | CAP - valve | 1 | |
| 17 | 33-211 | GASKET - adapter | 1 | |
|
33-211 OEM | Прокладка компрессора | 1 720 ₽ |
|
|
30-33-211 | Прокладка | 510 ₽ |
|
| 18 | 22-886 | ADAPTER - suction valve (2/95 & after) | 1 | |
| 19 | 22-719 | ADAPTER - valve (before 2/95) | 1 | |
| 20 | 55-2704 | SCREW - adapter | 4 | |
| 21 | 22-718 | SPACER - valve | 1 | |
| 22 | 66-6186 | VALVE - suction | 1 | |
| 23 | 33-350 | GASKET - cap | 1 | |
| 24 | 66-3015 | CAP - valve (brass, incl gasket) | 1 | |
|
10-66-3015 | Крышка сервисного клапана, латунь, X426/430/640 | 3 000 ₽ |
|
| P-17-10806-10 | Крышка сервисного клапана, латунь, 05K/05G/06D | 3 000 ₽ |
|
|
| 25 | 11-5513 | VALVE - test port | 1 | |
| 26 | 11-7777 | CORE - valve | 1 | |
| 27 | 55-5672 | CAP - valve | 1 | |
| 28 | 55-5874 | SCREW - valve | 2 | |
| 29 | 55-895 | FLATWASHER | 2 | |
| 30 | 55-5295 | SCREW - valve | 2 | |
| 31 | 55-896 | FLATWASHER | 2 | |
| 32 | 55-190 | SCREW - adapter | 4 | |
| 33 | 55-3364 | PLUG | 1 | |
| 34 | 204-972 | TOOL - keyway alignment | 1 |
