Установкa Thermo King схема BELTS, PULLEYS, FAN, ALTERNATOR (24V) – 126D14
Обновление от: 2/6/04
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 77-2320 | PULLEY - idler (see 126D13) | 1 | |
| 2 | 78-667 | BELT | 1 | |
| 10-78-667 | Ремень, SB-II, SB-II MAX, Isuzu 2.2 D.I., 2.2 S.E. | 2 640 ₽ |
|
|
| 3 | 77-1675 | PULLEY - water pump | 1 | |
| 4 | 77-2322 | SPACER - pulley | 1 | |
| 5 | 77-2323 | PULLEY - engine | 1 | |
| 55-8635 | SCREW - pulley | 4 | ||
| 55-5411 | LOCKWASHER | 4 | ||
| 6 | Not Used | |||
| 7 | 78-663 | FAN | 1 | |
| 55-6145 | SCREW - fan to pulley | 3 | ||
| 55-790 | LOCKWASHER | 3 | ||
| 8 | 55-2252 | SCREW - bracket | 1 | |
| 55-2159 | LOCKWASHER | 1 | ||
| 9 | 99-9272 | BRACKET - idler | 1 | |
| 10 | 91-441 | STRAP - idler | 1 | |
| 55-145 | SCREW - strap | 1 | ||
| 55-411 | FLATWASHER | 1 | ||
| 55-4118 | NUT | 1 | ||
| 11 | 55-5759 | SCREW - strap | 1 | |
| 55-4613 | WASHER - spacer | 1 | ||
| 12 | 55-4621 | NUT | 1 | |
| 13 | 99-9730 | BRACKET - idler | 1 | |
| 14 | 91-2397 | GUARD - belt | 1 | |
| 15 | 11-8774 | SPACER - engine pulley | 1 | |
| 16 | 78-985 | BELT - matched | 1 | |
| 17 | 91-462 | BRACKET - lower | 1 | |
| 55-172 | SCREW - bracket (5/16-18 x 1.25) | 2 | ||
| 55-2969 | SCREW - bracket (5/16-18 x 1) | 2 | ||
| 55-371 | FLATWASHER | 8 | ||
| 55-790 | LOCKWASHER | 4 | ||
| 55-312 | NUT | 4 | ||
| 18 | 91-466 | BRACE - alternator mount | 1 | |
| 55-5424 | SCREW (M8 x 1.25) | 1 | ||
| 55-4613 | FLATWASHER | 1 | ||
| 55-145 | SCREW (1/4-20) | 1 | ||
| 55-411 | FLATWASHER | 1 | ||
| 55-366 | LOCKWASHER | 1 | ||
| 55-291 | NUT | 1 | ||
| 19 | 91-6720 | BRACKET - alternator | 1 | |
| 55-4531 | SCREW - bracket (M14) | 1 | ||
| 55-7981 | LOCKWASHER | 1 | ||
| 55-8364 | FLATWASHER | 1 | ||
| 55-5090 | SCREW - bracket (M10) | 1 | ||
| 55-5411 | LOCKWASHER | 1 | ||
| 55-4625 | FLATWASHER | 1 | ||
| 55-5424 | SCREW - bracket (M8) | 1 | ||
| 55-790 | LOCKWASHER | 1 | ||
| 55-4613 | FLATWASHER | 1 | ||
| 20 | 55-5702 | SCREW - alternator | 1 | |
| 55-2173 | FLATWASHER | 1 | ||
| 55-2159 | LOCKWASHER | 1 | ||
| 21 | 55-2166 | NUT | 1 | |
| 22 | 41-3020 | ALTERNATOR (24V, 125 amp, see 78F8) | 1 | |
| 23 | 77-1089 | PULLEY - alternator | 1 | |
| 24 | 55-5058 | FLATWASHER | 1 | |
| 25 | 55-5321 | NUT | 1 | |
| 26 | 91-6721 | ARM - alternator adjusting | 1 | |
| 27 | 55-2252 | SCREW - arm | 1 | |
| 55-2159 | LOCKWASHER | 1 | ||
| 55-2173 | FLATWASHER | 1 | ||
| 28 | 55-529 | SCREW - arm | 1 | |
| 55-375 | LOCKWASHER | 1 | ||
| 55-402 | FLATWASHER | 1 | ||
| 29 | 91-467 | BRACKET - alternator adjusting arm | 1 | |
| 55-4647 | SCREW - bracket | 1 | ||
| 55-6479 | SCREW - bracket | 2 | ||
| 30 | 204-427 | GAUGE - belt tension | 1 |
