Установкa Thermo King схема REFRIGERATION COMPONENTS (T6-M10) – 125G10
Обновление от: 5/13/03
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1167 | COIL - condenser | 1 | |
| 55-1587 | SCREW - coil | 12 | ||
| 55-2086 | FLATWASHER | 24 | ||
| 55-4953 | NUT | 12 | ||
| 2 | 66-7371 | VALVE - expansion (R134a) | 1 | |
| 66-3592 | SCREEN - inlet | 1 | ||
| 66-4212 | ELEMENT - power | 1 | ||
| 55-5211 | U-BOLT - valve | 1 | ||
| 3 | 66-2170 | CAP - valve (plastic) | 3 | |
| 4 | 67-982 | TANK - receiver (see 97C11) | 1 | |
| 5 | 66-5805 | TUBE - condenser to receiver | 1 | |
| 66-4139 | FITTING - fan switch | 1 | ||
| 99-3060 | FITTING - relief valve | 1 | ||
| 6 | 66-7392 | VALVE - relief (see 119B8) | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 7 | 66-5809 | TUBE - indicator to valve | 1 | |
| 8 | 66-5806 | TUBE - receiver to subcool | 1 | |
| 9 | 66-5807 | TUBE - subcool to dehydrator | 1 | |
| 10 | 66-5810 | TUBE - shut-off valve to expansion valve | 1 | |
| 11 | 66-7116 | TUBE - suction | 1 | |
| 66-3570 | FITTING - saddle | 1 | ||
| 66-7117 | ADAPTER - suction | 1 | ||
| 12 | 66-7253 | TUBE - discharge | 1 | |
| 66-7330 | ADAPTER | 1 | ||
| 13 | 66-2104 | VALVE - shutoff | 1 | |
| 66-2170 | CAP - valve | 1 | ||
| 14 | 66-4176 | TUBE - valve to coil (discharge) | 1 | |
| 15 | 66-2648 | INDICATOR - liquid | 1 | |
| 66-9273 | INDICATOR - dry eye | 1 | ||
| 16 | 66-5808 | TUBE - dehydrator to indicator | 1 | |
| 17 | 99-9643 | BRACKET - tubes | 1 | |
| 33-573 | GROMMET - tube | 2 | ||
| 18 | 55-7706 | NUT - adapter (#16) | 1 | |
| 55-5741 | LOCKWASHER | 1 | ||
| 19 | 55-7709 | NUT - adapter | 1 | |
| 55-5742 | LOCKWASHER | 1 | ||
| 20 | 33-594 | O-RING - discharge | 1 | |
| 21 | 33-544 | O-RING - suction | 1 | |
| 22 | 66-6772 | TUBE - equalizer | 1 | |
| 23 | 66-4168 | TUBE - suction | 1 | |
| 24 | 67-1120 | COIL - heater | 1 | |
| 99-7871 | GASKET - heater/evaporator | 1 | ||
| 25 | 12-419 | HOSE (3/4 id x 25 ft, silicone) | A/R | |
| 33-572 | GROMMET (3/4 id) | 2 | ||
| 26 | 91-2632 | CLAMP - hose | 4 | |
| 27 | 66-4816 | PLATE & TUBE | 1 | |
| 28 | 99-7871 | GASKET - plate | 1 | |
| 29 | 11-5953 | HOSE (preformed) | 1 | |
| 30 | 67-1270 | COIL - evaporator | 1 | |
| 31 | 99-7803 | NUTSTRIP - coil | 4 | |
| 33-315 | GROMMET (1-5/16 id) | 2 | ||
| 33-572 | GROMMET (3/4 id) | 1 | ||
| 32 | 99-7862 | BRACKET - coil | 1 | |
| 33 | 99-7863 | BRACKET - coil | 1 | |
| 55-2969 | SCREW - bracket | 4 | ||
| 55-5032 | NUT - captive | 4 | ||
| 55-2958 | FLATWASHER | 8 | ||
| 55-2959 | LOCKWASHER | 4 | ||
| 34 | 55-4422 | FASTENER - snap | 2 | |
| 35 | 91-6289 | FILTER - air | 3 | |
| 36 | 44-7591 | VALVE & CONNECTOR | 1 | |
| 41-7599 | VALVE - solenoid (water, 24V, see 147A1) | 1 | ||
| 37 | 55-4397 | U-BOLT - solenoid | 2 | |
| 55-2086 | FLATWASHER | 4 | ||
| 55-4953 | NUT | 4 | ||
| 38 | 66-4817 | TUBE & ELBOW | 1 | |
| 39 | 11-6541 | HOSE - preformed | 1 | |
| 40 | 55-6042 | ELBOW | 1 | |
| 41 | 91-2628 | PLATE - solenoid | 1 | |
| 42 | 66-5804 | TUBE - hose support | 1 | |
| 43 | 91-4333 | BRACKET - coil (front) | 1 | |
| 44 | 91-4334 | BRACKET - coil (rear) | 1 | |
| 45 | 33-2377 | STRIP (rubber) | 1 | |
| 46 | 55-7489 | INSERT | 4 | |
| 47 | 55-2969 | SCREW - bracket | 2 | |
| 48 | 55-2959 | LOCKWASHER | 2 | |
| 49 | 55-2958 | FLATWASHER | 2 | |
| 50 | 66-4858 | DEHYDRATOR | 4 | |
| 51 | 66-4172 | VALVE - shutoff | 1 | |
| 52 | 55-308 | ELBOW - equalizer | 1 | |
| 53 | 66-5855 | TUBE - hose to elbow | 1 | |
| 54 | 55-3627 | COUPLING - reducing | 1 | |
| 55 | 66-5811 | TUBE | 1 | |
| 56 | 55-302 | NUT | 1 | |
| 57 | 44-6965 | SWITCH - condenser fan (for connectors see 115D14) | 1 | |
| 41-307 | SWITCH - only | 1 |
