Установкa Thermo King схема EVAPORATOR GROUP (RC-III) – 120C12
Обновление от: 7/14/95
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1099 | COIL - evaporator (see 108D12) | 1 | |
| 55-3490 | SCREW - coil | 8 | ||
| 55-2959 | LOCKWASHER | 8 | ||
| 55-2958 | FLATWASHER | 16 | ||
| 55-4954 | NUT | 4 | ||
| 2 | 91-5858 | PANEL - evaporator cover | 1 | |
| 55-7527 | SCREW - panel | 50 | ||
| 55-5223 | WASHER - dome | 50 | ||
| 55-3059 | NUT - captive | 30 | ||
| 3 | 91-4516 | ANGLE - panel (inner) | 6 | |
| 4 | 91-4517 | ANGLE - panel (outer) | 6 | |
| 55-5130 | RIVET - angle | 12 | ||
| 5 | 91-4518 | PLATE - air restriction | 4 | |
| 6 | 91-4519 | PLATE - air restriction (center) | 2 | |
| 55-5635 | SCREW - plate | 24 | ||
| 7 | 91-4520 | BRACKET - plate | 12 | |
| 55-3583 | RIVET | 16 | ||
| 8 | 98-4316 | DEFLECTOR - air | 1 | |
| 55-2979 | SCREW - deflector | 14 | ||
| 55-3045 | WASHER - dome | 14 | ||
| 9 | 91-5859 | MEMBER - air deflector | 7 | |
| 10 | 91-5860 | PAN - drain | 1 | |
| 11 | 33-2404 | STRIP - sealing | 1 | |
| 12 | 33-2530 | GASKET - sill (4 pieces) | 1 | |
| 13 | 91-4616 | STRIP | 1 | |
| 55-5130 | RIVET - blind | 14 | ||
| 14 | 33-2402 | STRIP - sealing | A/R | |
| 15 | 91-4684 | PLATE - sensor | 1 | |
| 55-2988 | RIVET | 1 | ||
| 16 | 98-4325 | PANEL - blower | 1 | |
| 17 | 33-612 | GROMMET | 1 | |
| 18 | 91-5622 | CLAMP - heat exchanger | 2 | |
| 55-3490 | SCREW - clamps | 4 | ||
| 55-2959 | LOCKWASHER | 4 | ||
| 55-2958 | FLATWASHER | 6 | ||
| 55-4954 | NUT | 2 | ||
| 19 | 91-4413 | BRACKET - valve | 1 | |
| 55-7529 | SPACER - clamp | 1 | ||
| 55-2977 | SCREW - bracket | 3 | ||
| 55-1800 | LOCKWASHER | 3 | ||
| 55-2086 | FLATWASHER | 3 | ||
| 55-3059 | NUT - captive | 3 | ||
| 20 | 55-7013 | CLAMP - tube | 1 | |
| 21 | 91-758 | CLAMP - tube | 1 | |
| 55-2977 | SCREW - clamp | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 22 | 91-5861 | HOSE - outer (curbside) | 1 | |
| 23 | 91-5862 | HOSE - inner (curbside) | 1 | |
| 24 | 91-5863 | HOSE - inner (roadside) | 1 | |
| 25 | 91-5864 | HOSE - outer (roadside) | 1 | |
| 26 | 66-1273 | VALVE - check | 4 | |
| 27 | 91-5865 | SCREEN - evaporator blower | 2 | |
| 55-5046 | RIVET - screen | 4 | ||
| 203-396 | ADHESIVE - rubber | A/R | ||
| 55-2330 | BANDWRAP | 6 | ||
| 99-3281 | MOUNT - cable tie | 5 | ||
| 55-5130 | RIVET - blind (5/32) | 5 |
