Установкa Thermo King схема T2-M107 REFERENCE SHEET – 11U22
Обновление от: 10/11/05
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 900285 | System - T2-M107 R22 | 10/05 | ||
| 600164 | T2-M107 | 10/05 | ||
| 700450 | Compressor Kit - X430 R22 | 10/05 | ||
| 815919 | Installation Kit | 10/05 | ||
| 040660 | T2 Generic | 10/05 | ||
| 040694 | Motor Ohio | 10/05 | ||
| 040683 | MP Diagnostic 24V | 10/05 | ||
| 040684 | Display Unit | 10/05 | ||
| 099051 | R22 EPR Valve | 10/05 | ||
| 099002 | Water Valve | 10/05 | ||
| 040671 | Nitrogen | 10/05 | ||
| 099054 | Compressor Harness | 10/05 | ||
| 040696 | w/o Driver Air Fitting | 10/05 | ||
| 040698 | Air Filter - Metal | 10/05 | ||
| 040701 | Condenser Coil | 10/05 | ||
| 040704 | Evaporator Coil | 10/05 | ||
| 040712 | Hose Clamp | 10/05 | ||
| 040714 | Access Panel | 10/05 | ||
| 040720 | Dehydrator Shutoff | 10/05 | ||
| 720697 | Fresh Air Kit | 10/05 |
