Установкa Thermo King схема SR-700 REFERENCE SHEET – 11U19

Обновление от: 10/6/06

Каталог запчастей для Thermo King SR-700 REFERENCE SHEET
№TK #ОписаниеКол-во
Цена
900361SR-700 10008/06
900362SR-700 10048/06
007258Electrical Circuiting SR-700 for ClimaAIRE w/Display8/06
720756ClimaAIRE II DP with Display w/Harness (Unit to Driver Panel - 9 m length)8/06
720757ClimaAIRE II DP with Display w/Harness (Unit to Driver Panel - 12 m length)8/06
720811ClimaAIRE II DP with Display w/Harness (Unit to Driver Panel - 15 m length)8/06
720758ClimaAIRE II DP with Display w/Harness (Unit to Driver Panel - 18 m length)8/06
700640Kit - ClimaAIRE I with Display w/Harness - 18 m8/06
700639Kit - ClimaAIRE I with Display w/Harness - 16 m8/06
700638Kit - ClimaAIRE I with Display w/Harness - 14 m8/06
700637Kit - ClimaAIRE I with Display w/Harness - 12 m8/06
700636Kit - ClimaAIRE I with Display w/Harness - 10 m8/06
700635Kit - ClimaAIRE I with Display w/Harness - 8 m8/06
700634Kit - ClimaAIRE I with Display w/Harness - 6 m8/06
720759Harness (A/C Unit to TM Compressor - 18 m length)8/06
720760Harness (A/C Unit to TM Compressor - 14 m length)8/06
720761Harness (A/C Unit to TM Compressor - 12 m length)8/06
720762Harness (A/C Unit to TM Compressor - 8 m length)8/06
700517Harness (A/C Unit to TM Compressor - 18 m length)8/06
700518Harness (A/C Unit to TM Compressor - 14 m length)8/06
700519Harness (A/C Unit to TM Compressor - 12 m length)8/06
700520Harness (A/C Unit to TM Compressor - 8 m length)8/06
719329Harness - ClimaAIRE (Unit to Compressor - 20 m length)8/06
719340Harness - ClimaAIRE (Unit to Compressor - 16 m length)8/06
719301Harness - ClimaAIRE (Unit to Compressor - 12 m length)8/06
719302Harness - ClimaAIRE (Unit to Compressor - 8.3 m length)8/06
700510Harness - ClimaAIRE (Unit to Compressor - 20 m length)8/06
700509Harness - ClimaAIRE (Unit to Compressor - 16 m length)8/06
700508Harness - ClimaAIRE (Unit to Compressor - 12 m length)8/06
700504Harness - ClimaAIRE (Unit to Compressor - 8.3 m length)8/06
007251Refrigerant Circuiting SR-700 - Standard8/06
007259Covers SR-700 for Flatter Bus Roof Radius8/06
007260Covers SR-700 for Smaller Bus Roof Radius8/06
007246Fresh Air Damper - SR-500W/SR-7008/06
007247No Fresh Air - SR-500W/SR-7008/06
720587Compressor X430-HPC, R134a, 24V, Pulley 2B/2A, 8.03 in/8.89 in8/06
720590Compressor X430-HPC, R134a, 24V, Pulley 12-K, Width 2.28 in, Dia 7.75 in8/06
700043Compressor FKX 40 / 470, Pulley 2SPB, ef. dia. 173 mm8/06
700044Compressor FKX 40 / 470, Pulley 9K, ef. dia. 147 mm8/06
700045Compressor FKX 40 / 470, Pulley 9K, ef. dia. 205 mm8/06
718377Compressor TM31, 24V, 2B Pulley, POE Oil8/06
719718Compressor TM31, 24V, 2A Pulley, POE Oil8/06
719222Compressor TM31, 24V, Polygroove Pulley, POE Oil8/06
718379Kit - POE Oil (can with 8 oz (0.24 Liters) for TM and A6 Compressor)8/06
880110Kit - Adapters for X430 Compressor (#16, #20)8/06
880099Kit - Installation SR-70 (Drain Hose 16 m)8/06
880258Kit - Installation SR-70 (Drain Hose 30 m)8/06
880098Return Air Grille - SR-708/06
007261Air Filter Optional SR-700 (Already Mounted in the Unit)8/06
700129Kit - Water Valve, 2-way Servomotor8/06
700130Kit - Water Valve, 3-way Servomotor8/06
700127Kit - Harness, Servomotor Water Valve, 10 m8/06
700128Kit - Harness, Servomotor Water Valve, 20 m8/06
700296Kit - Floor Temperature Sensor ClimaAIRE II (9 m)8/06
719055Kit - Water Pump, 27VDC, Hose - id 16 mm, 500 L/Hr8/06
719005Kit - Water Boost Pump, 27VDC, Hose Connections - id 38 mm, 5000 L/Hr8/06
719006Harness (Unit to Water Boost Pump - 14 m length)8/06
719007Harness (Unit to Water Boost Pump - 9 m length)8/06
719008Harness (Unit to Water Boost Pump - 7.6 m length)8/06
720320Kit - Adapters, id 19 mm / 38 mm8/06
719701Kit - Reheat Option (Software for ClimaAIRE - Factory Settings)8/06
720208Kit - Refrigerant Fittings, ORS (#20/#16 - S 0 deg/D 0 deg)8/06
720209Kit - Refrigerant Fittings, ORS (#20/#16 - S 45 deg/D 45 deg)8/06
720210Kit - Refrigerant Fittings, ORS (#20/#16 - S 90 deg/D 90 deg)8/06
720211Kit - Refrigerant Fittings, Flange (#20/#16 - S 0 deg/D 0 deg)8/06
720213Kit - Refrigerant Fittings, Flange (#20/#16 - S 45 deg/D 45 deg)8/06
720212Kit - Refrigerant Fittings, Flange (#20/#16 - S 90 deg/D 90 deg)8/06
720368Kit - Refrigerant Fittings, TM31 Compressor Side (#16/#12 - S 0 deg/D 0 deg)8/06
720369Kit - Refrigerant Fittings, TM31 Compressor Side (#16/#12 - S 45 deg/D 45 deg)8/06
720370Kit - Refrigerant Fittings, TM31 Compressor Side (#16/#12 - S 90 deg/D 90 deg)8/06
700840Kit - Refrigerant Fittings, TM31 Compressor Side (#16/#12 - S 90 deg/D 90 deg)8/06
720372Kit - Fittings, Flange (#16/#12 - S 90 deg/D 90 deg)8/06
720215Kit - Refrigerant Hose (#16, #20, 1 m without Fittings)8/06
720216Kit - Refrigerant Hose (#16, #20, 6 m without Fittings)8/06
720217Kit - Refrigerant Hose (#16, #20, 7 m without Fittings)8/06
720218Kit - Refrigerant Hose (#16, #20, 8 m without Fittings)8/06
720219Kit - Refrigerant Hose (#16, #20, 9 m without Fittings)8/06
720220Kit - Refrigerant Hose (#16, #20, 10 m without Fittings)8/06
720221Kit - Refrigerant Hose (#16, #20, 12 m without Fittings)8/06
720222Kit - Refrigerant Hose (#16, #20, 14 m without Fittings)8/06
720223Kit - Refrigerant Hose (#16, #20, 16 m without Fittings)8/06
720224Kit - Refrigerant Hose (#16, #20, 18 m without Fittings)8/06
720225Kit - Refrigerant Hose (#12, #16, 1 m without Fittings)8/06
720226Kit - Refrigerant Hose (#12, #16, 6 m without Fittings)8/06
720227Kit - Refrigerant Hose (#12, #16, 7 m without Fittings)8/06
720228Kit - Refrigerant Hose (#12, #16, 8 m without Fittings)8/06
720229Kit - Refrigerant Hose (#12, #16, 9 m without Fittings)8/06
720230Kit - Refrigerant Hose (#12, #16, 10 m without Fittings)8/06
720231Kit - Refrigerant Hose (#12, #16, 12 m without Fittings)8/06
720232Kit - Refrigerant Hose (#12, #16, 14 m without Fittings)8/06
720233Kit - Refrigerant Hose (#12, #16, 16 m without Fittings)8/06
720234Kit - Refrigerant Hose (#12, #16, 18 m without Fittings)8/06
720395Kit - Fittings for Tube Installation8/06
719305Kit - Alternator, 150A, 24VDC, 24V Excitation, 3.25 in for ClimaAIRE8/06
719306Kit - Alternator, 125A, 24VDC, 12V Excitation, 3.25 in for ClimaAIRE8/06
715247Kit - Muffler8/06
720242Kit - Refrigerant Hose Mix (#16, #20, 1 m without Fittings)8/06
720243Kit - Refrigerant Hose Mix (#16, #20, 6 m without Fittings)8/06
720244Kit - Refrigerant Hose Mix (#16, #20, 7 m without Fittings)8/06
720378Kit - Refrigerant Hose Mix (#16, #20, 8 m without Fittings)8/06
720379Kit - Refrigerant Hose Mix (#16, #20, 9 m without Fittings)8/06
720380Kit - Refrigerant Hose Mix (#16, #20, 10 m without Fittings)8/06
720381Kit - Refrigerant Hose Mix (#16, #20, 12 m without Fittings)8/06
720382Kit - Refrigerant Hose Mix (#16, #20, 14 m without Fittings)8/06
720383Kit - Refrigerant Hose Mix (#16, #20, 16 m without Fittings)8/06
720384Kit - Refrigerant Hose Mix (#16, #20, 18 m without Fittings)8/06
720385Kit - Refrigerant Hose Mix (#12, #16, 1 m without Fittings)8/06
720386Kit - Refrigerant Hose Mix (#12, #16, 6 m without Fittings)8/06
720387Kit - Refrigerant Hose Mix (#12, #16, 7 m without Fittings)8/06
720388Kit - Refrigerant Hose Mix (#12, #16, 8 m without Fittings)8/06
720389Kit - Refrigerant Hose Mix (#12, #16, 9 m without Fittings)8/06
720390Kit - Refrigerant Hose Mix (#12, #16, 10 m without Fittings)8/06
720391Kit - Refrigerant Hose Mix (#12, #16, 12 m without Fittings)8/06
720392Kit - Refrigerant Hose Mix (#12, #16, 14 m without Fittings)8/06
720393Kit - Refrigerant Hose Mix (#12, #16, 16 m without Fittings)8/06
720394Kit - Refrigerant Hose Mix (#12, #16, 18 m without Fittings)8/06
700256Kit - Suction T-Piece Fitting (DN22, 7/8 in-14UNF)8/06
700257Kit - Suction T-Piece Fitting (DN28, 7/8 in-14UNF)8/06
