Установкa Thermo King схема INSTALLATION GROUP (ECT-2) – 116G4
Обновление от: 11/27/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 55-3686 | NUT - unit | 4 | |
| 55-2038 | FLATWASHER | 8 | ||
| 55-5725 | WASHER - special | 4 | ||
| 2 | 99-7103 | HOSE - defrost drain | 4 | |
| 3 | 55-2686 | CLAMP - hose | 8 | |
| 4 | 67-1042 | TUBE - defrost (5/8 x 50 ft) | 1 | |
| 5 | 67-1041 | TUBE - suction (7/8 x 50 ft) | 1 | |
| 6 | 67-712 | TUBE - liquid (3/8 x 50 ft) | 1 | |
| 7 | 91-3541 | TUBE - insulating (5/8 id x 54 ft) | 1 | |
| 91-3542 | TUBE - insulating (7/8 id x 12 ft) | 1 | ||
| 99-6740 | TUBE - insulating (3/8 id x 12 ft) | 1 | ||
| 8 | 44-9437 | HARNESS - remote evaporator | 1 | |
| 9 | 44-8294 | CONNECTOR - shroud (6-pin) | 1 | |
| 10 | 44-7881 | CONNECTOR - tower (4-pin) | 1 | |
| 11 | 41-406 | HARNESS - evaporator (rear) | 1 | |
| 12 | 44-7872 | CONNECTOR - tower (6-pin) | 1 | |
| 13 | 44-7880 | CONNECTOR - shroud (4-pin) | 1 | |
| 14 | 66-7295 | TUBE - hot gas | 1 | |
| 15 | 66-7296 | TUBE - suction | 1 | |
| 16 | 66-7297 | TUBE - liquid line | 1 | |
| 17 | 66-637 | ELBOW (7/8 solder) | A/R | |
| 55-2187 | ELBOW (5/8 solder) | A/R | ||
| 55-2876 | ELBOW (3/8 solder) | 2 | ||
| 18 | 55-1203 | CLAMP (7/8) | A/R | |
| 55-2666 | CLAMP (1-5/16) | A/R | ||
| 55-6033 | SCREW - clamp | A/R | ||
| 19 | 44-9205 | HARNESS - low voltage | 1 | |
| 20 | 41-407 | HARNESS - remote rear evaporator | 1 | |
| 21 | 44-5838 | CONNECTOR - tower (2-pin) | 1 | |
| 22 | 41-408 | HARNESS - evaporator (rear, motor & circuit breaker) | 1 | |
| 23 | 44-5835 | CONNECTOR (2 terminal, see 115D14) | 1 |
