Установкa Thermo King схема CONTROL PANEL ASSEMBLY (M25) – 112E7
Обновление от: 5/29/01
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-2293 | PANEL - control | 1 | |
| 55-1587 | SCREW - panel | 6 | ||
| 55-2086 | FLATWASHER | 6 | ||
| 55-1800 | LOCKWASHER | 6 | ||
| 2 | 91-3100 | NAMEPLATE - panel | 1 | |
| 3 | 44-5494 | BREAKER - circuit (65 amp) | 3 | |
| 55-2513 | SCREW - breaker | 6 | ||
| 55-3013 | FLATWASHER | 6 | ||
| 55-3014 | LOCKWASHER | 6 | ||
| 4 | 44-6044 | JUMPER - circuit breaker | 1 | |
| 5 | 41-3987 | SOLENOID - evaporator/condenser fan | 4 | |
| 55-1587 | SCREW - solenoid | 8 | ||
| 55-2086 | FLATWASHER | 15 | ||
| 55-1800 | LOCKWASHER | 1 | ||
| 55-3059 | NUT - captive | 8 | ||
| 6 | 44-6007 | DIODE | 3 | |
| 7 | 44-5537 | SOCKET - relay | 9 | |
| 55-3027 | SCREW - socket | 5 | ||
| 55-2001 | FLATWASHER | 5 | ||
| 55-2964 | LOCKWASHER | 5 | ||
| 55-4508 | NUT - captive | 3 | ||
| 8 | 44-9111 | RELAY - mini (12VDC) | 3 | |
|
10-44-9111 | Реле | 1 310 ₽ |
|
| 9 | 44-9112 | RELAY - mini (24VDC) | 6 | |
| 10 | 44-7216 | BREAKER - circuit (10 amp) | 2 | |
| 55-3843 | SCREW - breaker | 4 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-2964 | LOCKWASHER | 4 | ||
| 11 | 44-8747 | SENSOR - thermostat | 1 | |
| 12 | 55-3484 | CLAMP - sensor | 1 | |
| 55-3027 | SCREW - clamp | 1 | ||
| 55-2001 | FLATWASHER | 1 | ||
| 55-2964 | LOCKWASHER | 1 | ||
| 13 | 91-2295 | COVER - thermostat | 1 | |
| 14 | 44-7476 | THERMOSTAT - electronic | 1 | |
| 15 | 55-1801 | NUT - ground (1/4-20) | 2 | |
| 55-2699 | LOCKWASHER (internal/external tooth) | 1 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-2993 | LOCKWASHER (internal tooth) | 1 | ||
| 16 | 44-7377 | DIODE - assembly | 1 | |
| 17 | 33-415 | GROMMET (5/8 id) | 1 | |
| 18 | 44-4551 | BOARD - terminal | 1 | |
| 55-2868 | SCREW - board | 2 | ||
| 55-3013 | FLATWASHER | 4 | ||
| 55-3014 | LOCKWASHER | 2 | ||
| 55-2999 | NUT (hex) | 2 | ||
| 19 | 91-3103 | MARKSTRIP | 1 | |
| 20 | 44-8676 | RESISTOR | 1 | |
| 21 | 44-8008 | BREAKER - circuit (20 amp) | 1 | |
| 55-3843 | SCREW - breaker | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 22 | 44-6428 | TIMER - solid state | 1 | |
| 55-5279 | SCREW | 1 | ||
| 55-3013 | FLATWASHER | 1 | ||
| 55-3014 | LOCKWASHER | 1 | ||
| 23 | 99-3427 | MOUNT - cable tie | 4 | |
| 55-3010 | RIVET - mount | 4 | ||
| 24 | 44-8118 | POTENTIOMETER | 1 | |
| 91-903 | KNOB | 1 | ||
| 25 | 44-3579 | STRIP - jumper | 1 |
