Установкa Thermo King схема RELAY BOARD ASSEMBLY – 111D12
Обновление от: 5/24/95
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-9333 | BOARD - relay | 1 | |
| 91-4565 | NAMEPLATE - This Socket Not Used | 1 | ||
| 2 | 91-1277 | RETAINER - harness connector | 3 | |
| 55-2262 | RIVET - retainer | 3 | ||
| 55-3550 | FLATWASHER | 6 | ||
| 3 | 41-895 | RELAY (1pdt) | 2 | |
|
30-41-895 | Реле | 1 650 ₽ |
|
| 4 | 44-3186 | RELAY (3pdt) | 1 | |
|
10-44-3186 | Реле оттайки, KD/MD/RD/TD/URD-III / SB-I/II/III / SMX | 3 440 ₽ |
|
| 5 | 99-2027 | SPRING - holddown | 1 | |
| 55-2262 | RIVET - spring | 4 | ||
| 55-2771 | CLAMP - speednut | 1 | ||
| 6 | 44-8168 | RESISTOR | 1 |
