Установкa Thermo King схема SUPER-II 30 190Y TIER 2 ENGINE REFERENCE SHEET – 10U13
Обновление от: 3/29/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 920374 | System - Super-II 30 190Y Tier 2 Engine | 3/06 | ||
| 004042 | Super-II 30 190Y Tier 2 Engine | 3/06 | ||
| 812490 | Kit - Installation Box | 3/06 | ||
| 004035 | External Battery (Tapered Post) | 1/05 | ||
| 004036 | External Battery (Threaded Post) | 1/05 | ||
| 004037 | Internal Battery (Threaded Post) | 1/05 | ||
| 004044 | 190Y DAS Tier 2 Engine | 3/06 | ||
| 004045 | 190Y DAS/ETV Tier 2 Engine | 3/06 | ||
| 004046 | 190Y ETV Tier 2 Engine | 3/06 | ||
| 004047 | Fuel Heater | 3/06 | ||
| 092050 | Add SII Bumpers | 3/06 | ||
| 002078 | ESOC Fittings | 1/05 | ||
| 048678 | Frost Plug Heater | 3/06 | ||
| 092175 | Compound Pressure Gauge | 3/06 | ||
| 092280 | Fresh Air Exchanger | 1/05 | ||
| 718350 | DAS Sensor - 10 ft | 3/06 | ||
| 718351 | DAS Sensor - 20 ft | 3/06 | ||
| 718352 | DAS Sensor - 40 ft | 3/06 | ||
| 718353 | DAS Sensor - 60 ft | 3/06 | ||
| 718354 | DAS Sensor - 80 ft | 3/06 | ||
| 714701 | Remote Light Kit | 3/06 | ||
| 715589 | Remote Status Light Kit | 3/06 | ||
| 715288 | Kit - RC Flush SL/SB-III/SII | 3/06 | ||
| 093016 | Remote Dual Sensors | 3/06 | ||
| 048776 | Fuel Tank - 110 Gallon 22 Inch Dia Aluminum | 3/06 | ||
| 048601 | Fuel Tank - 30 Gallon 22 Inch Dia Aluminum | 3/06 | ||
| 048602 | Fuel Tank - 50 Gallon 22 Inch Dia Aluminum | 3/06 | ||
| 048603 | Fuel Tank - 50 Gallon 22 Inch Dia Aluminum | 3/06 | ||
| 048725 | Fuel Tank - 50 Gallon Aluminum 18 Inch Dia Aluminum | 3/06 | ||
| 002155 | Fuel Tank - 120 Gallon Aluminum | 3/06 | ||
| 002156 | Fuel Tank - 120 Gallon 22 Inch Dia Aluminum | 3/06 | ||
| 002184 | Fuel Tank - 75 Gallon 22 Inch Dia Aluminum | 3/06 | ||
| 002136 | Fuel Tank - 50 Gallon Aluminum 22 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002137 | Fuel Tank - 30 Gallon Aluminum 22 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002138 | Fuel Tank - 110 Gallon Aluminum 22 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002139 | Fuel Tank - 50 Gallon Aluminum 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002140 | Fuel Tank - 30 Gallon Aluminum 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002141 | Fuel Tank - 50 Gallon Steel 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002142 | Fuel Tank - 50 Gallon Steel 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002143 | Fuel Tank - 50 Gallon Steel 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002144 | Fuel Tank - 50 Gallon Aluminum 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002145 | Fuel Tank - 30 Gallon Aluminum 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002146 | Fuel Tank - 50 Gallon Aluminum 22 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002147 | Fuel Tank - 30 Gallon Aluminum 22 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002148 | Fuel Tank - 110 Gallon Aluminum 22 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002149 | Fuel Tank - 50 Gallon Aluminum 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002150 | Fuel Tank - 30 Gallon Aluminum 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002151 | Fuel Tank - 50 Gallon Aluminum 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002152 | Fuel Tank - 50 Gallon Steel 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 002153 | Fuel Tank - 50 Gallon Steel 18 Inch Dia w/ Fuel Level Sensor | 1/05 | ||
| 004058 | Super-II Grille | 3/06 | ||
| 714567 | Fuel Tank Kit - 50 Gallon 22 inch | 3/06 | ||
| 720063 | Fuel Level Sensor Kit | 3/06 | ||
| 720840 | Fuel Level Sensor - 22 Inch | 3/06 | ||
| 720841 | Fuel Level Sensor - 18 Inch | 3/06 |
