Установкa Thermo King схема HARNESS ASSEMBLY (STBci2 10DRT & 20DRT) – 107G14
Обновление от: 11/27/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-9760 | HARNESS | 1 | |
| 2 | 91-981 | NAMEPLATE - Accessories | 1 | |
| 3 | 41-743 | CONNECTOR - round (14-pin, male) | 1 | |
| 44-8538 | CLAMP - cable | 1 | ||
| 4 | 44-5838 | CONNECTOR (2-pin, female) | 3 | |
| 91-4342 | NAMEPLATE - heat | 1 | ||
| 5 | 44-5835 | CONNECTOR (2-pin, male) | 5 | |
| 91-982 | NAMEPLATE - Liquid Injection Switch | 1 | ||
| 6 | 44-7330 | CONNECTOR - shroud (1-pin) | 3 | |
| 91-978 | NAMEPLATE - Compressor Clutch | 1 | ||
| 7 | 91-979 | NAMEPLATE - Battery (Positive) | 1 | |
| 91-980 | NAMEPLATE - Battery (Negative) | 1 | ||
| 8 | 44-9569 | CONNECTOR - shroud (3-pin) | 1 | |
| 9 | 44-7881 | CONNECTOR - tower (4-pin) | 2 | |
| 10 | 44-7327 | CONNECTOR - tower (1-pin) | 1 | |
| 11 | 55-5112 | CONNECTOR - liquid tite | 1 | |
| 12 | 44-7872 | CONNECTOR - tower (6-pin) | 1 | |
| 91-4341 | NAMEPLATE - power pack | 1 | ||
| 13 | 44-9761 | CONNECTOR - jumper (6-pin, male) | 1 | |
| 14 | 44-9762 | CONNECTOR - jumper (4-pin, male) | 1 |
