Установкa Thermo King схема EVAPORATOR (EW) – 107A5
Обновление от: 8/25/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-4234 | HOUSING | 1 | |
| 2 | 98-4233 | COVER - front panel | 1 | |
| 55-3188 | NUT - speed | 12 | ||
| 55-736 | SCREW - cover | 12 | ||
| 3 | 99-2420 | CHANNEL - heater | 4 | |
| 4 | 45-1012 | HEATER (1000W) | 3 | |
| 5 | 99-7647 | CHANNEL - drain pan | 2 | |
| 6 | 99-4085 | BRACKET - air switch | 1 | |
| 55-1049 | SCREW - bracket | 2 | ||
| 55-5292 | NUT (hex) | 2 | ||
| 7 | 66-4487 | SWITCH - air pressure differential | 1 | |
| 99-1143 | HOSE - air switch | 1 | ||
| 8 | 99-1275 | PROBE - switch | 1 | |
| 10-99-1275 | Зонд | 800 ₽ |
|
|
| 55-3136 | RIVET - probe | 1 | ||
| 9 | 55-3248 | ELBOW | 1 | |
| 55-3627 | COUPLING | 1 | ||
| 10 | 66-6575 | TUBE - defrost | 1 | |
| 11 | 99-8239 | BRACKET - solenoid | 1 | |
| 12 | 67-1094 | COIL - evaporator | 1 | |
| 55-4974 | NUT - captive | 4 | ||
| 33-1117 | STRIP - sealing (rubber) | 2 | ||
| 55-1049 | SCREW - evaporator | 5 | ||
| 13 | 66-5744 | VALVE - solenoid (see 116G14) | 2 | |
| 99-261 | CONNECTOR | 1 | ||
| 55-1804 | BUSHING | 2 | ||
| 14 | 99-7653 | BRACKET - solenoid | 1 | |
| 55-736 | SCREW - bracket | 2 | ||
| 55-4560 | NUT (hex) | 2 | ||
| 55-3029 | SCREW - valve | 2 | ||
| 15 | 66-6211 | TUBE - inlet | 1 | |
| 16 | 66-6574 | TUBE - outlet | 1 | |
| 17 | 66-5993 | VALVE - expansion (R502) | 1 | |
| 66-5335 | ELEMENT - power | 1 | ||
| 66-6047 | SCREEN - inlet | 1 | ||
| 55-3357 | CLAMP - valve | 1 | ||
| 18 | 66-5050 | TUBE - suction | 1 | |
| 55-5752 | ADAPTER | 1 | ||
| 19 | 66-5128 | VALVE - solenoid (see 138A4) | 1 | |
| 20 | 66-6572 | TUBE - coil to tee | 1 | |
| 66-5752 | FITTING | 1 | ||
| 21 | 99-3033 | GUARD - evaporator fan | 1 | |
| 22 | 55-315 | NUT - guard | 4 | |
| 55-336 | LOCKWASHER - nut | 4 | ||
| 55-411 | FLATWASHER | 4 | ||
| 23 | 78-701 | FAN - evaporator | 1 | |
| 24 | 99-3032 | MOUNT - motor | 2 | |
| 99-4520 | STRIP (rubber) | 2 | ||
| 55-1049 | SCREW | 2 | ||
| 55-5292 | NUT (hex) | 2 | ||
| 25 | 44-8528 | MOTOR | 1 | |
| 44-8054 | BRUSH & END BELL | 1 | ||
| 77-1461 | BEARING | 2 | ||
| 44-2590 | FUSE | 1 | ||
| 44-4620 | HOLDER - fuse | 1 | ||
| 26 | 55-3742 | PLUG - button | 3 | |
| 27 | 44-6255 | BOARD - terminal | 1 | |
| 55-3416 | SCREW - board | 2 | ||
| 55-2996 | LOCKWASHER | 2 | ||
| 55-4560 | NUT (hex) | 2 | ||
| 91-2187 | MARKSTRIP | 1 | ||
| 28 | 99-7651 | COVER - access | 1 | |
| 55-5656 | SCREW - cover | 4 | ||
| 29 | 66-6573 | TUBE - equalizer line | 1 | |
| 30 | 91-902 | BRACKET - tube | 1 | |
| 31 | 91-901 | BRACKET - solenoid (suction) | 1 | |
| 32 | 99-7645 | PLATE - cover | 1 | |
| 55-5656 | SCREW - cover | 4 | ||
| 33 | 99-4613 | COVER - fan | 1 | |
| 55-1049 | SCREW - cover | 4 | ||
| 55-5292 | NUT (hex) | 4 | ||
| 34 | 41-1514 | SWITCH - defrost termination | 1 | |
|
10-41-1514 | Датчик окончания оттайки | 14 220 ₽ |
|
| 55-5655 | SCREW - switch | 2 | ||
| 35 | 99-7650 | SHIELD - thermo bulb | 1 | |
| 55-3404 | SCREW - shield | 2 | ||
| 55-5292 | NUT (hex) | 2 | ||
| 36 | 55-547 | CLAMP - bulb | 2 | |
| 37 | 44-5235 | SENSOR - thermo | 2 | |
| 38 | 66-3655 | VALVE - check | 1 | |
| 39 | 55-4131 | ADAPTER - defrost (3/8 flare) | 1 | |
| 40 | 66-5046 | TUBE - defrost | 1 | |
| 41 | 66-5047 | TUBE - tee to check valve | 1 | |
| 42 | 66-5048 | TUBE - check valve to tee | 1 | |
| 43 | 66-5049 | TUBE - tee to valve | 1 | |
| 44 | 66-620 | TEE - suction | 1 | |
| 45 | 55-2296 | TEE - defrost | 1 | |
| 46 | 99-6095 | PIPE - drain | 1 | |
| 47 | 99-9538 | HOSE - drain | 1 | |
| 48 | 44-3627 | SWITCH - high temperature cutout | 1 | |
| 55-1049 | SCREW - switch | 2 |
