Установкa Thermo King схема BELTS, PULLEYS, FAN & ORIFICE GROUP – 106C5
Обновление от: 9/12/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 78-783 | FAN - evaporator | 2 | |
| 2 | 55-2307 | SCREW - fan | 2 | |
| 3 | 98-3726 | ORIFICE - condenser fan | 1 | |
| 4 | 98-3725 | PLENUM - condenser | 1 | |
| 5 | 99-3261 | BOLTPLATE - fanshaft | 2 | |
| 6 | 78-782 | FANSHAFT - assembly (see 77A3) | 2 | |
| 7 | 55-2641 | FLATWASHER | 8 | |
| 8 | 55-4955 | NUT - fanshaft (stop) | 8 | |
| 9 | 78-800 | BELT - evaporator fan to compressor | 1 | |
| 10-78-800 | Ремень компрессор - вентиляторы испарителя, RD-II | 4 070 ₽ |
|
|
|
PP-78-800 | Ремень компрессор - вентиляторы испарителя, RD-II | 1 260 ₽ |
|
| 10 | 78-977 | BELT - hydraulic motor to compressor | 1 | |
| 10-78-977 | Ремень компрессора, KD/MD-II | 14 420 ₽ |
|
|
| PP-78-977 | Ремень компрессора, KD/MD-II | 5 150 ₽ |
|
|
| 11 | 78-766 | BELT - alternator to evaporator fan | 1 | |
| 10-78-766 | Ремень генератор - вентилятор испарителя, RD/TD-II | 4 980 ₽ |
|
|
| PP-78-766 | Ремень генератор - вентилятор испарителя, RD/TD-II | 840 ₽ |
|
|
| 12 | 78-898 | BELT - motor to compressor | 1 | |
| 10-78-898 | Ремень электромотора, TD/RD-II | 7 620 ₽ |
|
|
| 13 | 55-457 | KEY - pulley & fan | 4 | |
| 14 | 77-1921 | PULLEY - evaporator fan | 2 | |
| 55-3089 | SCREW - pulley | 4 | ||
| 55-2959 | LOCKWASHER | 4 | ||
| 15 | 104-483 | MOTOR (380/3/50, see 106C6) | 1 | |
| 77-2503 | BEARING (front & rear) | 2 | ||
| 55-9128 | BOLT - thru | 4 | ||
| 91-1719 | BARB - fitting | 1 | ||
| 55-2635 | NUT | 1 | ||
| 99-9700 | NAMEPLATE - 380VAC 50 Hz 3 phase | 1 | ||
| 55-4164 | KEY - pulley/fan | 2 | ||
| 16 | 77-1924 | PULLEY - alternator | 1 | |
| 17 | 44-9754 | ALTERNATOR (37 amp, model EA, see 90E9) | 1 | |
|
10-41-2195 | Генератор 37A, MD/RD/TD-II / SB-II/III | 19 510 ₽ |
|
| 41-2195 | ALTERNATOR (37 amp, model 8MR) | 3 | ||
|
|
10-41-2195 | Генератор 37A, MD/RD/TD-II / SB-II/III | 19 510 ₽ |
|
| 18 | 77-2365 | PULLEY - motor | 1 | |
| 55-2962 | SCREW - pulley | 2 | ||
| 55-2959 | LOCKWASHER | 2 | ||
| 19 | 77-1925 | PULLEY - compressor | 1 | |
| 55-9024 | KEY - pulley | 1 | ||
|
10-55-9024 | Шпонка коленвала, X418/426/430 | 590 ₽ |
|
| 77-2498 | SPACER | 1 | ||
|
10-77-2498 | Шайба муфты сцепления | 990 ₽ |
|
| 55-375 | LOCKWASHER | 1 | ||
| 20 | 77-2102 | PULLEY - hydraulic motor (see 106C10) | 1 | |
| 21 | 78-781 | FAN - condenser | 1 | |
| 55-2963 | SCREW - fan | 4 | ||
| 55-2958 | FLATWASHER | 4 | ||
| 55-2959 | LOCKWASHER | 4 | ||
| 22 | 98-3727 | GUARD - fan | 1 | |
| 55-2977 | SCREW - guard | 4 | ||
| 55-3045 | LOCKWASHER - dome | 4 | ||
| 55-3059 | NUT - captive | 4 | ||
| 23 | 204-972 | TOOL - keyway alignment | 1 | |
| 24 | 204-427 | GAUGE - belt tension | 1 |
