Установкa Thermo King схема POWER PACK SUBASSEMBLY - FRONT – 103E9
Обновление от: 6/26/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-2262 | COVER - engine timing belt (front) | 1 | |
| 91-2263 | COVER - engine timing belt (rear) | 1 | ||
| 2 | 11-3262 | HOSE - water (1/2 id x 13-1/2 in) | 1 | |
| 55-2686 | CLAMP - hose | 2 | ||
| 3 | 91-2259 | BRACKET - tube | 1 | |
| 55-145 | SCREW - bracket | 2 | ||
| 55-4118 | NUT (hexstop) | 2 | ||
| 4 | 55-3648 | CLAMP - tube | 1 | |
| 55-145 | SCREW - clamp | 1 | ||
| 55-411 | FLATWASHER | 1 | ||
| 55-4118 | NUT (hexstop) | 1 | ||
| 11-2532 | HOSE (1-3/8 id) | 1 | ||
| 5 | 11-7242 | TUBE - engine outlet | 1 | |
| 11-7243 | HOSE (1-3/8 id x 4 in) | 1 | ||
| 55-3402 | CLAMP - hose | 2 | ||
| 6 | 91-2247 | BRACKET - engine alternator adjusting | 1 | |
| 55-3486 | SCREW (1/2-13 x 1-1/2, hh) | 2 | ||
| 55-2173 | FLATWASHER | 2 | ||
| 55-2159 | LOCKWASHER | 2 | ||
| 7 | 78-459 | BELT - engine drive | 1 | |
| 8 | 91-2248 | BRACKET - alternator adjusting arm | 1 | |
| 55-5579 | SCREW - bracket | 2 | ||
| 55-5411 | LOCKWASHER | 2 | ||
| 9 | 91-2261 | COVER - timing belt | 1 | |
| 55-5579 | SCREW - cover | 1 | ||
| 55-5411 | LOCKWASHER | 1 | ||
| 10 | 11-7256 | FITTING - banjo (complete) | 1 | |
| 11-4372 | HOSE (3/8 od x 35 ft lg) | A/R | ||
| 11 | 11-7255 | FITTING - banjo (complete) | 1 | |
| 10-242 | KIT - sleeve & eyelet (3/8) | 1 | ||
|
P-40-00342-02 | Фитинг топливной магистрали | 1 040 ₽ |
|
| 11-4941 | NUT (3/8) | 1 | ||
| 11-5607 | ELBOW (3/8) | 1 | ||
| 11-4372 | HOSE (3/8 od x 35 ft lg) | A/R | ||
| 12 | 11-7253 | ADAPTER - throttle rod | 1 | |
| 11-7254 | ADAPTER - throttle rod | 1 | ||
| 11-4874 | CLIP - clevis | 1 | ||
| 11-4874 OEM | Клипса тяги соленоида, SB-II/III / SMX/SMX-II / SL/Sle | 2 850 ₽ |
|
|
| 55-2965 | NUT (hex) | 4 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 13 | 55-3648 | CLAMP - tube | 1 | |
| 11-2532 | HOSE (1-3/8 id) | 1 | ||
| 14 | 91-2260 | BRACKET - tube | 1 | |
| 55-6763 | SCREW - bracket | 1 | ||
| 55-2959 | LOCKWASHER | 1 | ||
| 15 | 44-7673 | SOLENOID - throttle | 1 | |
| 55-2762 | BOLT - eye | 1 | ||
|
10-55-2762 | Шток | 1 050 ₽ |
|
| 91-3059 | COVER - plunger | 1 | ||
| 99-328 | BOLTSTRIP - solenoid | 2 | ||
| 55-4953 | NUT | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 16 | 55-2330 | BANDWRAP | 4 | |
| 17 | 91-2253 | BRACKET - solenoid valve | 1 | |
| 55-5022 | SCREW - bracket | 2 | ||
| 55-371 | FLATWASHER | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 18 | 11-9262 | INDICATOR - air restrictor | 1 | |
| 19 | 11-4372 | HOSE (3/8 od x 35 ft lg) | A/R | |
| 20 | 11-7526 | FILTER - fuel (w/ primer, see 103F8) | 1 | |
| 11-7531 | FITTING - banjo | 2 | ||
| 55-2961 | SCREW - filter | 2 | ||
| 55-4955 | NUT | 2 | ||
| 55-2641 | FLATWASHER | 2 | ||
| 21 | 91-3576 | BRACKET - fuel pump/primer | 1 | |
| 55-2969 | SCREW - bracket | 2 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 55-4954 | NUT | 2 | ||
| 22 | 44-6016 | SENSOR - rpm | 1 | |
|
10-44-6016 | Датчик оборотов двигателя, SB-I/II/III / MD-200/300 / TS-200/300 | 8 900 ₽ |
|
| PP-44-6016 | Датчик оборотов двигателя, SB-I/II/III / MD-200/300 / TS-200/300 | 4 310 ₽ |
|
|
| 23 | 91-2246 | BRACKET - engine mount (front) | 1 | |
| 55-5424 | SCREW - bracket | 4 | ||
| 55-4647 | SCREW - bracket | 1 | ||
| 55-371 | FLATWASHER | 6 | ||
| 55-790 | LOCKWASHER | 5 | ||
| 55-4621 | NUT | 2 | ||
| 55-6756 | SPACER - tubular | 1 | ||
| 24 | 101-277 | ENGINE - assembly | 1 | |
| 91-2264 | COVER - flywheel housing | 1 | ||
| 25 | 98-3828 | MOUNT - engine (front) | 1 | |
| 55-5579 | SCREW - engine mount | 4 | ||
| 55-5411 | LOCKWASHER | 4 | ||
| 26 | 41-3020 | ALTERNATOR (see 73F8) | 1 | |
| 77-1089 | PULLEY - alternator | 1 | ||
| 55-5058 | WASHER - special (pulley) | 1 | ||
| 55-5702 | SCREW - alternator | 1 | ||
| 55-2173 | FLATWASHER | 1 | ||
| 55-2159 | LOCKWASHER | 1 | ||
| 55-2166 | NUT | 1 |
