Установкa Thermo King схема CONDENSER FRAME & DOORS – 100B6
Обновление от: 2/12/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-3958 | FRAME - condenser (before 2/93) | 1 | |
| 98-4365 | FRAME - condenser (after 1/93) | 1 | ||
| 2 | 91-2991 | COVER - top (aluminum) | 1 | |
| 98-5411 | COVER - top (composite, use to replace an aluminum cover) | 1 | ||
| 98-5981 | COVER - top (composite, use to replace a composite cover) | 1 | ||
| 33-558 | GROMMET | 8 | ||
| 55-2292 | WASHER - special | 2 | ||
| 55-7035 | SCREW - cover | 8 | ||
| 55-7619 | WASHER - special | 8 | ||
| 55-6996 | LOCKWASHER | 6 | ||
| 55-7042 | NUT | 8 | ||
| 3 | 98-6476 | PANEL - upper, center | 1 | |
| 55-6994 | SCREW - panel | 6 | ||
| 55-2945 | WASHER - special | 6 | ||
| 55-6996 | LOCKWASHER | 6 | ||
| 55-7075 | WASHER - special | 1 | ||
| 55-6997 | NUT - captive | 4 | ||
| 55-7042 | NUT | 3 | ||
| 4 | 98-4324 | GRILLE - roadside (steel) | 2 | |
| 98-4088 | GRILLE - roadside (stainless steel) | 2 | ||
| 98-3970 | SCREEN - grille | 2 | ||
| 98-3969 | FRAME - screen | 2 | ||
| 55-7035 | SCREW - grille | 4 | ||
| 55-6996 | LOCKWASHER | 4 | ||
| 55-2838 | WASHER - special | 4 | ||
| 55-6997 | NUT - captive | 4 | ||
| 5 | 91-5750 | HINGE - grille | 2 | |
| 6 | 91-5751 | HINGE - grille | 4 | |
| 55-3588 | RIVET - hinge | 12 | ||
| 55-7036 | SCREW - hinge | 12 | ||
| 55-7033 | FLATWASHER | 24 | ||
| 55-7034 | NUT | 12 | ||
| 7 | 98-3967 | BAND - center | 1 | |
| 98-4079 | INSERT - band (optional) | 1 | ||
| 55-2988 | RIVET - insert | 2 | ||
| 55-7035 | SCREW - band | 6 | ||
| 55-7075 | FLATWASHER | 10 | ||
| 55-6996 | LOCKWASHER | 6 | ||
| 55-7042 | NUT | 4 | ||
| 55-6991 | INSERT - threaded | 2 | ||
| 8 | 98-6479 | PANEL (curbside) | 1 | |
| 9 | 91-2995 | HINGE - panel (top) | 1 | |
| 10 | 91-2996 | HINGE - panel (bottom) | 1 | |
| 91-4847 | SPACER (after 11/92) | 1 | ||
| 11 | 91-2998 | LATCH - door (top) | 1 | |
| 12 | 98-6478 | DOOR - front (curbside) | 1 | |
| 91-5057 | BUMPER - front door | 1 | ||
| 33-1435 | GROMMET - bumper | 5 | ||
| 13 | 98-6477 | DOOR (roadside) | 1 | |
| 55-5960 | BUSHING | 4 | ||
| 55-6994 | SCREW - block | 8 | ||
| 55-6995 | FLATWASHER | 8 | ||
| 55-6996 | LOCKWASHER | 8 | ||
| 14 | 91-2997 | LATCH - door (bottom) | 1 | |
| 55-6994 | SCREW - latch | 5 | ||
| 55-7075 | FLATWASHER | 5 | ||
| 55-6996 | LOCKWASHER | 4 | ||
| 55-7042 | NUT | 4 | ||
| 15 | 91-4577 | HINGE | 1 | |
| 16 | 91-4578 | HINGE (curbside) | 1 | |
| 91-3001 | BOLTSTRIP - hinge | 1 | ||
| 55-6994 | SCREW - hinge | 4 | ||
| 55-6996 | LOCKWASHER | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 55-7042 | NUT | 4 | ||
| 17 | 91-4368 | LATCH - door | 1 | |
| 99-9973 | SPRING - latch (cw, top) | 1 | ||
| 99-9974 | SPRING - latch (ccw, bottom) | 1 | ||
| 91-2704 | RETAINER - handle | 2 | ||
| 91-4189 | NUTSTRIP | 2 | ||
| 18 | 91-4578 | HINGE (roadside) | 1 | |
| 19 | 91-4580 | HINGE (roadside) | 1 | |
| 91-3001 | BOLTSTRIP - hinge | 1 | ||
| 55-6994 | SCREW - hinge | 4 | ||
| 55-6995 | LOCKWASHER | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 55-7042 | NUT | 4 | ||
| 20 | 91-3007 | PANEL - cover | 1 | |
| 21 | 91-3008 | BRACKET - panel | 1 | |
| 22 | 91-3107 | SCREEN - top | 1 | |
| 55-6994 | SCREW - screen | 8 | ||
| 55-6996 | LOCKWASHER | 8 | ||
| 55-7075 | FLATWASHER | 8 | ||
| 55-6997 | NUT | 8 | ||
| 23 | 33-2918 | GASKET - sill | 1 | |
| 24 | 91-5212 | BLOCK - hinge | 2 | |
| 55-5960 | BUSHING | 2 | ||
| 25 | 91-3009 | STRIKE - top (before 6/92) | 1 | |
| 91-4139 | STRIKE - top (6/92 & after) | 1 | ||
| 26 | 91-3181 | STRIKE - door | 1 | |
| 27 | 91-3519 | SCREEN (roadside) | 1 | |
| 28 | 91-3518 | SCREEN (curbside) | 1 | |
| 29 | 91-3520 | SCREEN - pulley | 1 | |
| 55-7035 | SCREW - screen | 15 | ||
| 55-6996 | LOCKWASHER | 15 | ||
| 55-7075 | WASHER - special | 15 | ||
| 30 | 91-4377 | LOCK - door (w/ key, before 6/93) | 1 | |
| 33-1435 | GROMMET | 1 | ||
| 91-537 | KEY | 1 | ||
| 91-5213 | LOCK - door (w/ key, 6/93 & after) | 1 | ||
| 91-537 | KEY | 1 | ||
| 31 | 91-2498 | STRAP - door | 2 | |
| 32 | 91-3059 | TRIM - box (side) | 1 | |
| 33 | 91-3058 | TRIM - box (bottom) | 1 | |
| 34 | 91-5131 | BRACKET - hinge | 1 | |
| 55-7172 | SCREW - bracket | 4 | ||
| 55-6996 | LOCKWASHER | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 35 | 91-7203 | BLOCK - hinge | 2 |
